Maintenance Instructions LUBRICATION
50
Ident Lubrication No.
No. Location Type Places
Ident Lubrication No.
No. Location Type Places
1 Deck Caster Wheel Fork Pivot Grease 2
2 Blade Drive Gearbox Oil* 2
3 Tee Gearbox, Deck Oil* 1
4 Deck Caster Wheel Bearing Grease 2
5 PTO Shaft Guard Hinge Oil 1
6 Universal Joint Shaft Assembly Grease** 1
7 Pivot Assembly, Tilt-Up Deck Grease 4
8 Deck Support Arm Socket Grease 2
9 Body Hinge Point Oil 2
10 FSC Actuator Rod Pivot Pins Oil 2
11 FSC Lever Pivot Grease 1
12 FSC Lever Fork Grease 1
(Grease Slide Area)
13 (FSC) Friction Body Pivot Grease 1
14 Steering Lever Pivot Grease 4
15 Deck Roller Wheel Oil 2
16 Deck Support Arm Pivot Grease 2
17 Deck-to-PTO Coupling Grease 1
18 Universal Joint Tube Assembly Grease** 1
19 Universal Joint Quick Connect Grease 1
Spline (Grease Slide Area)
20 Parking Brake Lever Grease 1
21 Gear Axle Oil*** 2
22 Belt Tightener Pivot, Grease 1
Ground Drive
23 PTO Clutch Lever Pivot Grease 1
24 Clutch Actuator Push Rod Grease 2
%UDNH$FWXDWRU5RGDQG%UDNH 2LO
Band Pivot Pins (Clevis)
26 Idler Arm Oil 1
27 Engine Belt Idler Pulley Oil 1
28 Throttle Control Cable Ends Oil 2
29 Cold Start Lever Grease 1
30 Rear Bumper Roller Wheel Oil 2
31 Catcher Hinge Point Oil 2
32 Rear Wheel Axle Grease 2
33 Engine Dipstick / Oil Filler Oil*** 1
34 Blower Belt Idler Pulley Grease 1
35 PTO Gearbox Dipstick Oil 1
36 Ground Drive Idler Pulley Oil 2
37 Hydrostatic Drive Oil*** 2
38 Throttle Control Assembly Oil 1
39 Discharge Chute Hinge Oil 1
40 Steering Lever Support Oil 1
* Gearboxes are permanently lubricated and
sealed requiring no scheduled lubrication.
Oil level should be checked only when an oil
leak is noted. Refer to Mower Deck Gear-
box Lubrication in this section.
** Grease every eight (8) hours.
*** Refer to Gear Axle Lubrication, Engine
Oil, Tractor PTO Gearbox Lubrication, and
Hydrostatic Transmission Fluid in this sec-
tion.
NOTE: DGHS42 Tilt-Up Deck is shown for reference.
For other Deck Lubrication Points, Refer to
Deck and Carrier Frame Illustrated Parts
Manual.
