SAFETY, CONTROL, AND INSTRUCTION DECALS
Safety, Control, and Instruction Decals are installed on the machine;
if any are missing, illegible, or damaged, a replacement should be ordered and installed before
putting the machine into operation. The Decal Part Number is listed below and in the Parts Manual.
Location: Right Side, Behind Operator Seat
Part Number: 8600-23
1. Warning – entanglement hazard.
• Remove ignition key before raising front
body.
2. Body Tilt Latch
• Raise lever to release.
• Lift at back of body to raise.
1.
1. Caution - Pinch point.
• Keep all body parts clear when closing grass
catcher door.
Location: Catcher Door Hinge Bar,
LH and RH Sides
Part Number: 8600-10
Location: Bridge Assembly and
LH Gear Axle
Part Number: 5810-3
8600-23
1.
2.
1. Warning – read Operator’s Manual before servic-
ing or performing maintenance.
• Engage parking brake.
• Remove ignition key.
2. Forward Speed Control
• Move lever forward to increase speed; back
to stop.
3. Warning – do not operate the machine without a
deck or other implement attached.
4. PTO Clutch Lever
• Move lever back to engage PTO clutch; for-
ward to disengage.
5. Warning – do not engage PTO clutch with PTO
shaft disconnected.
Location: RH Fender
Part Number: 8600-33
1. 2.
2.
3.
1.
4.
5.
