Recording Model Serial Number
Table of Contents
BEFORE OPERATING YOUR NEW EQUIPMENT, please locate the tractor model plate and engine mode plate on the equipment and copy the informa-
tion to the sample model plates provided to the below. You can locate the tractor model plate either beneath the seat pivot plate, or on the front/right
side of the frame. The engine identification is located on a decal (or decals) affixed to the engine shrouding. This information will be necessary to use
the manufacturer’s web site, to obtain assistance from the Customer Support Department, or when contacting an authorized service dealer.
This Operator’s Manual is an important part of your new lawn mower. It will help you assemble,
prepare, and maintain the unit for best performance. Please read and understand what it says.
Customer Support
Slope Gauge............................................................... 3
Safe Operation Practices .......................................... 4
Setup and Adjustment .............................................. 8
Operating Your Lawn Mower ................................... 10
Making Adjustments .............................................. 17
Maintaining Your Lawn Mower ................................ 20
Off-Season Storage ................................................. 29
Optional Attachments ............................................ 29
Safety Labels .......................................................... 30
Troubleshooting ...................................................... 31
Replacement Parts ................................................. 33
Warranties ............................................................... 34
If you have difficulty operating this product or have any questions regarding the controls, operation, or maintenance of this unit, you can contact the
dealer you purchased the unit from or choose from the options below:
Model Number Serial Number
www.cubcadet.com
CUB CADET LLC
P. O. BOX
361131
CLEVELAND, OH 44136
DEALER LOCATOR PHONE NUMBER:
877-282-8684
1. Visit www.cubcadet.com for many useful suggestions. Click on
Customer Service or the Service Locator to find the nearest Cub
Cadet service dealer in your area.
2. To reach the Customer Dealer Referral Line, please call 1-877-282-
8684.
3. The engine manufacturer is responsible for all engine-related issues
with regards to performance, power-rating, specifications, warranty
and service. Please refer to the engine Owner’s/Operator’s Manual for
more information.
KOHLER CO. KOHLER, WISCONSIN USA
EMISSION COMPLIANCE PERIOD:
EPA: CARB:
CERTIFIED ON:
REFER TO OWNER'S MANUAL FOR HP RATING,
SAFETY, MAINTENANCE AND ADJUSTMENTS
1-800-544-2444 www.kohlerengines.com
FAMILY
TYPE APP
DISPL. (CC)
MODEL NO
.
SPEC. NO.
SERIAL NO.
BUILD DATE
OEM PROD. NO.
IMPORTANT ENGINE INFORMATION
THIS ENGINE MEETS U.S. EPAAND CA 2005 AND
LATER AND EC STAGE II (SN:4) EMISSION REGS
FOR SI SMALL OFF–ROAD ENGINES
