RC5010 & RC6010 (540 RPM) and RCM5010 & RCM6010 (1000 RPM) Rotary Cutters 318-128M 8/28/08
Land Pride
Section 5: Maintenance & Lubrication
Table of Contents
Constant Velocity Driveline
Joints & Shields
Type of Lubrication: Multi-purpose Grease
• The constant velocity joint should be greased in a
straight position forcing grease through the passages
and into the cavity. After lubrication, grease should
be visible around the ball joints.
• The constant velocity driveline comes equipped with
a grease zerk in the outer telescoping member and
must be greased every 8 hours to prevent premature
failure of the joint.
• Grease fittings are located on the u-joints and
driveline shields and should be lubricated every 8
hours of operation.
NOTE: To extend the life of the constant velocity
joint, extensive lubrication must be performed every
8 hours of operation.
8
Hrs
Constant Velocity Driveline
Profile Tubes
Type of Lubrication: Multi-purpose Grease
Quantity = Coat Generously
20
Hrs
Drivelines with internal tube grease point
23565
Zerk Located on end of tube
Drivelines with external tube grease point
15312
Zerk located through slot in tubes
Drivelines with internal tube grease point
23565
Drivelines with external tube grease point
15312
