Section 5 Features and Benefits
10/28/05
Land Pride
Table of Contents
BH25 Series Backhoes
Features Benefits
Tractor HP Range 30 - 65 HP
Hitch – 3-Point Rigid Hitch Mount with Stabilizing Kit for Maximum digging stability.
Skid Loader Mountings Selected Mounting Kits available for added versatility.
Tubular Construction Tubular and box designed frame on boom and dipper stick assemblies for added strength
and longer life.
Relief Valve Protection One master and four circuit relief valves with anti-cavitation feature to protect against
accidental overloads and errors in operation.
Wide Stance Stabilizer Legs Wide support base with large steel foot pads for stable and safe operational control.
Optional Rubber Street Pads Rubber pads can be added to steel stabilizer pads when using on concrete to keep from
sliding.
Plated and Locked Wear Pins Plated and locked pins on all pivot points for added safety.
Pivot Point
Replaceable Bushings
All pivot points have replaceable and greaseable plated wear bushings for longer life.
Double Acting Cylinders With Nitro-Steel black piston rods for superior wear and corrosive resistance over chrome
shafts. High quality internal seals for dependable long life performance.
Six spool valve Two lever hydraulic valve with excellent feathering characteristics and minimum cylinder
cavitation for easy operation and control.
Safety Boom Lock Standard on all models for transportation safety.
Hydraulic Swing Cushion
Protection
Patented swing cushion slows down and stops swing automatically, prevents ‘shock loads’ at
the end of arm travel.
Two Double Acting Swing
Cylinders
One cylinder pushing and one pulling for a powerful, smooth and controllable swing arch.
Lower Drawbar Link Locks Standard on all models for more stability in operation and less stress in transportation.
Hydraulic Hose Protection Abrasive-resistant coverings for longer life.
Adjustable Folding Seat Offering more comfort and room for operation and less operator fatigue.
Hydraulic Pressure Gauge Kit Standard equipment and positioned on control valve for easy observation.
Independent
Hydraulic System
Optional with 540 gear type pump
Bucket Options 9” to 36” Bucket options
Power Beyond Option Control valve adaptability - available as an optional kit.
Digging Depth
Maximum Range
9’-0”
Maximum Reach from Swing
Point
11’-2”
Swing Arch 180 degrees
Bucket Rotation 180 degrees
Bucket Pry Out Power 6,725 lbs.
Lift power at End of Boom 733 lbs.
Section 5 Features and Benefits
