Section 4 Specifications and Capacities
10/28/05
Land Pride
Table of Contents
Section 4 Specifications and Capacities
BH25 Series Backhoes
BH2585
Tractor Horsepower Rating 30-65 HP
Maximum Digging Depth 9’
Digging Depth 2” Flat Bottom 8’ 6”
Reach from Swing Pivot 11’ 2”
Transport Height 7’ 8”
Bucket Clearance or Loading Height 7’ 6”
Bucket Curl 180 deg.
Swing Arc 180 deg.
Stabilizer Spread-Folded Down, Operating Position 9’ 4”
Stabilizer Spread-Folded Up, Transport Position 5’ 10”
Hydraulic System Four lever six-spool control valve
Main Circuit Relief 2200 PSI
4 individual circuit reliefs
Hydraulic Fluid Minimum 6.0 GPM
Hydraulic Fluid Maximum 8.0 GPM
Boom Lifting Power
(boom straight out, dipper stick at 90 deg.)
733 lbs. (less bucket)
Boom Lifting Power
(boom and dipper stick extended)
582 lbs.
Bucket Cylinder Digging Force 3,591 lbs.
Dipper Stick Cylinder Digging Force 2,510 lbs.
Bucket Pryout Power (partially curled) 6,725 lbs.
Tractor 3-Point Hitch Cat. 1 & 2
Skid Steer Skid Steer Mount Option
Hydraulic Cylinders Equipped with NitroSteel corrosive resistant black shafting
Swing Cylinders Dual-Hydraulic swing system
Swing Shock Absorbers At the end of each swing
Pins Locked in place, grease zerks at pivot points
Transport Lock Safety transport boom flip-over lock
Bushings Replaceable, steel at all major pivot points
Hydraulic Pressure Gauge Standard
Adjustable Hinged Seat Standard
