iOptron 8507 Telescope User Manual



5
Electronic eyepiece to bring the video/images to you computer screen
With the 1.3 megapixel electronic eyepiece (Model #8506 only), you can experience astro-video
and astrophotography for yourself! It allows you to view real-time images from your telescope on
a computer screen. It transmits live video images of the Sun, Moon, planets and terrestrial
objects through a USB cable to your computer. Images can be recorded for later playback or
frame imaging.
Package Contents
1
(1) SmartStar
®
Cube
TM
–E mount
(1) Refractor Telescope with glass solar filter (60mm)
(1) GoToNova
®
hand controller (Part # 8405)
(1) Controller cable
(1) 90º star diagonal
(1) Eyepiece (25mm)
(1) Tripod
(1) Soft bag
(1) 1.3M electronic eyepiece (Model #8506 only)
(1) USB cable (Model #8506 only)
1.2. SmartStar
®
Solar 60
TM
Assembly Terms
1. Telescope
2. Dovetail Lock
3. Hand Controller
4. Altitude Lock
5. Mount
6.
Diagonal
7. Eyepiece
8. Tripod
9. Thread-on solar filter
Warning: once the solar filter is removed from the telescope, it will no longer be a Solar
Scope. Never aim the telescope at the sun if the solar filter is removed or damaged.
1
Package contents may vary without notice
6
7
5
8
9
6
7
5
8
9
