SKU 95014 For technical questions, please call 1-800-444-3353 PAGE 7
ASSEMBLY INSTRUCTIONS
To Attach The Handle Bars:
1. To attach the two Handle Bars (6) to the Tank (1), lay the Tank on a flat, level
surface with its Handle Bar mounting brackets facing up. (See Figure B.)
2. The Handle Bars (6) are labeled “Left” and “Right”. Align the holes in the left
Handle Bar with the Handle Bar mounting brackets on the left side of the Tank
(1). (See Figure B.)
3. Place a Washer (50) onto each of the four Handle Bar mounting Screws (8).
Insert a Screw through each of the holes in the Handle Bar and Handle Bar
mounting brackets. Then, screw a Hex Nut (9) onto each of the Screws and
firmly tighten. (See Figure B.)
4. Repeat Steps #2 and #3 for the right Handle Bar (6) to the Tank (1).
(See Figure B.)
FIGURE B
6
8
50
9
3
4
1
5
51
2
3
To Attach The Wheels And Front Foot:
1. Locate the two Wheels (2), three Cotter Pins (3), Wheel Axle (5), four Wheel
Washers (51), and Front Foot (4).
2. Slide the Wheel Axle (5) through the axle holes located at the bottom of the two
Handle Bars (6). (See Figure B.)
