PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front cover.
Keep this manual and invoice in a safe and dry place for future reference.
SAFETY WARNINGS AND PRECAUTIONS
1. Do not operate the Pressurized Abrasive Blaster if the Air Supply Valve
(18) does not turn the tool on or off. Any tool that cannot be controlled with its
Air Supply Valve is dangerous and must be replaced.
SKU 95014 For technical questions, please call 1-800-444-3353 PAGE 2
UNPACKING
When unpacking, check to make sure that all the parts and accessories listed on pages
15 and 16 are included, and the product is intact and undamaged. If any parts are missing
or broken, please call Harbor Freight Tools at the number shown on the cover of this manual
as soon as possible.
2. Keep work area clean. Cluttered areas invite accidents.
3. WARNING! Do not operate pneumatic equipment in explosive
atmospheres, such as in the presence of flammable liquids, gases, or dust.
Pneumatic equipment can create sparks which may ignite flammables.
Item Description
Media Tank Capacity 110 Pounds or 20 Gallons
Working PSI 60 to 125 PSI
Air Consumption 6 CFM @ 60 PSI / 25 CFM @ 125 PSI (with 3/8” Hose)
Air Inlet Size 1/4”-18 NPT
Water Trap Type Push Button to Drain
Hose Dimensions 1/2” I.D. x 1” O.D. x 8’-6” Long
Pressure Gauge Indicator 0 <-> 150 PSI (White Face / Red Numbers)
Recommended Media Type Glass Bead / Silicon Carbide
Alumina / Walnut Shell / Brass Bead
Accessories Safety Hood / Blast Gun / Funnel
Ceramic Nozzles (2.0mm, 2.5mm, 3mm)
Overall Dimensions 35-1/2” High x 15” Diameter
Unit Weight 60 Pounds
