7.3 HOOD AND BAG ASSEMBLY – LAZER Z HP 44, 48, 52, & LAZER Z 52 (cont.)
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 1-653396 Hood .....................................1 31 114974-03 Clamp .....................................1
2 1-653397-03 Stiffener, bagger top..............1 32 3230-1 5/16-18x.75 Carriage bolt ....... 2
3∀
1-652395-03 Hinge wldmt ..........................2 33 3296-29 5/16-18 nyloc nut .................... 2
ϕ
103-0825-03 Hinge wldmt RH ....................2
34∀
1-654389 Cloth bag ................................ 1
ϕ
103-0826-03 Hinge wldmt LH .....................2
ϕ
103-0431 Cloth bag ................................ 1
4 114967 Screen ...................................1 35 1-653566 Bag handle.............................. 1
5 114439 3/16x.5 Pop rivet ...................38 36 3229-1 1/4-20x.75 Carriage bolt ......... 2
6 1-803075 #10-24x.75 CRTH Screw ......10 37 1-653036 Washer .344x1.75x.062 pltd... 2
7 3256-14 .219x.500x.049 Flat washer ..14 38 3296-42 1/4-20 nyloc nut....................... 2
8 3296-2 #10-24 nyloc nut....................10 39 1-653404 Catch ......................................1
9 1-653561 Seal, chute ............................1 40 3290-500 #10-24x.625 CRPH Screw...... 2
10 1-653598-03 Clamp, seal ...........................1 41 1-809112 #10-24 whizlock nut ................ 2
11∀
1-653425 Seal .......................................1 42 1-652414-03 Bag support wldmt.................. 1
ϕ
103-1346 Seal .......................................1 43 32128-33 1/4-20 whizlock nut.................1
12 1-653400-03 Support, screen.....................1 44 1-523420 Bumper ................................... 1
13 1-653519 Mount, latch...........................1
45∀
1-652308-03 Bagger mount wldmt............... 1
14 1-653036 Washer .344x1.75x.062 pltd .2 46 322-5 5/16-18x1 Screw 44”, 48” only 8
15 321-4 1/4-20x.75 Hex Head Screw .6 322-9 5/16-18x1.75 Screw (LHP 52”only)8
16 32128-33 1/4-20 whizlock nut................6
•
322-12 5/16-18x2.50 Screw................ 8
17 1-653403 Latch......................................1 47◆ 1-654597 Hood assembly – service only 1
18 1-653535 Latch reinforcement ..............1
48∀
1-808289 Clevis Pin................................2
19 321-11 1/4-20x2.0 Hex Head Screw .1 49 1-806005 Hair Pin...................................2
21 3296-42 1/4-20 nyloc nut.....................3 50 32128-20 5/16-18 whizlck nut (LHP 52”only)4
22 321-6 1/4-20x1.00 Hex Head Screw2
51•
103-0325-03 Tube, Spacer .......................... 2
23∀
1-652305-03 Bagger upright wldmt ............1
52ϕ
103-0429-03 Bagger Mount Wldmt.............. 1
ϕ
103-1310-03 Bagger upright wldmt ............1
53ϕ
103-0398-03 Bracket Frame LH ..................1
24 3256-2 Flat washer .312x.734x.065…2
54ϕ
103-0399-03 Bracket Frame RH..................1
25 1-633545 Spacer .................................... 2
55ϕ
3290-357 3/8-16 Whizlock nut ............... 8
26 1-653544 Spring ..................................... 2
56ϕ
98-5975 Spring disk washer ................. 8
27 322-2 5/16-18x.62 Hex Hd Screw .... 4
57ϕ
323-6 3/8-16-1.0 Screw ................... 8
28 1-653528-03 Plate, backing......................... 1
58ϕ
283-69 Clevis Pin................................2
29 1-653529-03 Frame, bag............................. 1 59*
∀
1-654390 Bag Assembly......................... 1
30 114973-03 Hanger, bag............................ 1
*ϕ
103-0435 Bag Assembly......................... 1
◆ Includes items 1,2,4,7,12,13,18 riveted together and Decal
• Used in Adapter Kit 103-0328 for Lazer HP model LHP4818KC below Serial Number 176621 only
* Includes items 29 through 38.
∀ Items on Lazer Z HP units only.
ϕ Items on Lazer Z 52” units only.
