- 18 -
Rotate ignition switch to “OFF” position. Remove the key to prevent children or
other unauthorized persons from starting engine.
Close fuel shut-off valve when machine will not be used for a few days, when
transporting, and when the unit is parked inside a building.
5.2.3 Engaging PTO:
DANGER
POTENTIAL HAZARD
♦ The rotating blades under the mower deck are
dangerous.
WHAT CAN HAPPEN
♦ Blade contact can cause serious injury or kill you.
HOW TO AVOID THE HAZARD
♦ DO NOT put hands or feet under the mower or mower
deck when the blades are engaged.
DANGER
POTENTIAL HAZARD
♦ An uncovered discharge opening will allow objects to
be thrown in an operator’s or bystander’s direction.
Also, contact with the blade could occur.
WHAT CAN HAPPEN
♦ Thrown objects or blade contact can cause serious
injury or death.
HOW TO AVOID THE HAZARD
♦ Never operate the mower with the discharge deflector
raised, removed, or altered unless there is a grass
collection system or mulch kit in place and working
properly.
The PTO switch engages the cutting blades. Be sure that all persons are clear
of mower deck and discharge area before engaging the PTO.
IMPORTANT: Operator must be in seat before the PTO can be engaged.
Set throttle to "midway" position. The switch must be pulled out to the "ROTATE"
position to engage the blades. Accelerate to full throttle to begin mowing.
5.2.4 Stopping PTO: Set throttle to “idle” position. Push in on the switch to the “STOP”
position to stop the blades.
5.3 TRANSPORTING
5.3.1 Transporting a Unit: Use a heavy duty trailer to transport the machine. When the
machine is on the trailer lower the cutting deck and fully extend the actuator.
Never transport machine with mower deck supported by actuator, damage to the
actuator or other components may occur. Engage the park brake and block the
wheels. Securely fasten the machine to the trailer or truck with straps, chains,
cables, or ropes. Be sure that the trailer or truck has all necessary lighting and
marking as required by law. Secure to trailer with a safety chain.
5.3.2 Loading a Unit: Use caution when loading units on a trailer or truck. Use
actuator to lift cutting deck off of the ground to provide more traction on the drive
tires while loading the unit. One full width ramp that is wide enough to extend
beyond the drive tires is recommended. If it is not possible to use one full width
ramp, multiple ramps may be used, but should be spaced close enough together
