MOTION CONTROL GROUP
-7-
Item
Part No.
Description
Qty.
1 1-543017 Balljoint..................................................2
2 3296-4 Nut, Esna 5/16-24..................................2
3 1-633181 Plate, Tapped.........................................2
4 1-633257 Grip, Control Lever.................................2
5 1-809057 Screw, SH 5/16-18 x 3/4 .......................4
6 65-7410 Switch....................................................2
7 98-5975 Washer, Spring Disc 3/8.........................4
8 103-9367 Asm, Lever Control (RH) W/Grip............1
9 103-9368 Asm, Lever Control (LH) W/Grip.............1
10 103-9373 Trunnion.................................................2
11 103-9407 Rod, Steering.........................................2
12 103-9411 Wld, Steering Control (RH).....................1
13 103-9413 Wld, Steering Control (LH).....................1
14 103-9414 Post, Lever Mount..................................2
15 103-9928 Bearing ..................................................4
16 104-7201 Nut, Nyloc 1/4-20 Flg .............................4
17 104-8300 Nut, Nyloc 5/16-18 Flg ...........................4
Item
Part No.
Description
Qty.
18 104-8301 Nut, Nyloc 3/8-16 Flg.............................2
19 109-2339 Damper, Motion Control.........................2
20 109-2423 Shaft, Control Pivot................................2
21 109-2428 Bracket, Damper Mount.........................2
22 1-633545 Spacer...................................................4
23 322-6 Screw, HH 5/16-18 x 1 1/4.....................2
24 323-6 Screw, HH 3/8-16 x 1.............................4
25 323-9 Screw, HH 3/8-16 x 1 3/4.......................2
26 3220-2 Nut, Jam 5/16-24...................................6
27 3229-4 Bolt, Carriage 1/4-20 x 1 1/2..................4
28 3234-7 Screw, HH FLG 5/16-18 x 5/8................4
29 3256-24 Washer, 3/8 SAE...................................2
30 32128-20 Nut, Whizlock 5/16-18............................4
31 3272-10 Pin, Cotter 1/8 x 3/4...............................2
32 3290-500 Screw, PPH #10-24 x 5/8.......................4
33 32128-33 Nut, Whizlock 1/4-20..............................4
