SEAT GROUP
-9-
Item
Part No.
Description
Qty.
1 27-0410 Screw, Shoulder 5/16-18 x 1 Sp.............2
2 63-8410 Washer ..................................................4
3 82-2190 Switch....................................................1
4 103-3999 Decal, Exmark Logo...............................1
5 103-9376 Bumper, Seat.........................................2
6 104-8300 Nut, Nyloc 5/16-18 Flg ...........................4
7 109-3128 Asm, Seat W/Decals..............................1
8 109-2427-03 Bar, Seat Stop........................................1
Item
Part No.
Description
Qty.
9 116-0950 Decal, Service Aid.................................1
10 109-2607-03 Bracket, Seat.........................................1
11 109-2608 Spacer...................................................4
12 108-6163 Kit, Armrest............................................1
13 32144-4 Screw, HWH 1/2-20 x 1/2 Taptite...........2
14 322-10 Screw, HH 5/16-18 x 2...........................4
15 1-653036 Washer..................................................4
Exmark black touch up spray paint – gloss black.
