Maintenance
Maintenance Service
Interval
Maintenance Procedure
Before storage
• Charge the battery and disconnect the battery cables.
• Perform all maintenance procedures before storage.
• Paint any chipped surfaces.
Monthly
• Check the battery charge.
Important: Refer to your Engine Operator’s Manual for additional maintenance procedures.
Premaintenance
Procedures
Raising the Seat
Make sure the motion control levers are locked in
the neutral position. Lift the seat forward until the
lanyard is tight. The following components can be
accessed by raising the seat:
• Auxiliary 12V Plug (12V accessory up to 15 amp)
• Fuses
• Battery cables
Accessing the Battery
The battery is located under the seat. To access, raise
the seat (Figure 16).
Figure 16
1. Auxiliary 12V Plug
3. Seat
2. Battery
Periodic Maintenance
Lubrication
Greasing the Bearings
Service Interval: Every 25 hours/Monthly
(whichever comes rst)
Grease Type: NGLI grade #2 multi-purpose gun
grease.
Grease the front caster wheels (Figure 17).
1
G007184
Figure 17
1. Front caster tire
1. Park the machine on a level surface and disengage
the blade control switch.
2. Move the motion control levers outward to the
neutral position, engage parking brake, stop the
engine, remove the key, and wait for all moving
parts to stop before leaving the operating position.
3. Clean the grease ttings (Figure 17 and Figure 18)
with a rag. Make sure to scrape any paint off of
the front of the tting(s).
29
