FRONT FRAME GROUP
-7-
Item
Part No.
Description
Qty.
1V 109-2072 Asm, Front Frame (60”) .........................1
V
109-2073 Asm, Front Frame (66”) .........................1
V
109-2074 Asm, Front Frame (72”) .........................1
2 302-19 Zerk, 1/4-28 Straight ..............................5
3 109-1903 Asm, Floorpan (103-8274-01)
W/Decals...............................................1
4 1-543509 Bearing Cone, Tapered Roller................4
5 103-2084 Asm, Lever (103-2083-03)W/Grip ..........1
6 1-633295 Grip, Lift Lever .......................................1
7 103-9529-03 Arm Wldmt, Deck Lift............................1
8 1-633325 Spring, Compression .............................1
9 3256-24 Washer, 3/8 SAE Flat ............................1
10 3296-39 Nut, Nyloc 3/8-16...................................4
11 32151-103 E-Ring....................................................5
12 1-633068 Arm, Deck Lift........................................2
13 1-633889-01 Plate, Deck Lift.......................................1
14 109-1900 Wld, Deck Lift Plate ...............................1
15 1-633082 Bushing, Lift Lever.................................1
16 109-3193 Stop, Deck Height..................................1
17 323-13 Screw, 3/8-16 x 2 3/4.............................1
18 1-633097 Hitch Pin W/Lanyard..............................1
19 1-806005 Hairpin Cotter.........................................1
20 323-9 Screw, 3/8-16 x 1 3/4.............................2
21 98-5975 Washer, 3/8 Disc Spring........................12
22 3290-357 Nut, Whizlock 3/8-16..............................15
23 323-6 Screw, 3/8-16 x 1...................................1
24 323-7 Screw, 3/8-16x1 1/4...............................12
25 3256-29 Washer, 7/8 SAE Flat ............................4
26 1-633096 Rod, Deck Lift........................................2
27 3217-11 Nut, 5/8-11 Regular................................6
28 1-633441 Swivel, Deck Mount ...............................4
Item
Part No.
Description
Qty.
29 3256-7 Washer, 5/8 Std Flat..............................4
30 109-4963 Spring, Deck Support.............................2
31 103-4882 Cap, Grease..........................................2
32 3218-6 Jam Nut, 5/8-11.....................................6
33 109-1902 Asm, Floorpan, Liftout (103-8276-01)
W/Decal.................................................1
34 1-543511 Seal, Grease..........................................2
35 103-1474-01 Caster Wldmt.........................................2
36 3296-51 Nut, 3/4-10 Nyloc...................................2
37 1-633508 Washer, Spring Disc..............................6
38 325-39 Screw, 1/2-13 x 9 1/2.............................2
39 1-811010 Plug.......................................................2
40 103-2768 Guard, Seal ...........................................4
41 3296-23 Nut, 1/2-13 Nyloc...................................2
42 3230-1 Bolt, Carriage 5/16-18 x 3/4...................4
43 103-0063 Seal, Bearing.........................................4
44 1-633585 Bearing Cone.........................................4
45 32128-20 Nut, Whizlock 5/16-18 ...........................4
46 103-5156 Axle, Caster...........................................2
47 103-1918 Bushing .................................................2
48 323-29 Screw, 3/8-16 x 1 3/8.............................2
49 32151-29 Ring, Retaining......................................2
50 3274-18 Screw, Socket HD5/16-18x1 1/4............2
51 1-543508 Bearing Cup, Tapered Roller .................4
52 103-3051 Spacer, Nut ...........................................4
53 109-9127 Asm, Caster Wheel (Semi-Pneumatic)..2
54 3218-2 Jam Nut, 5/16-18...................................2
55 103-9741-01 Weldmt, Front Lift Shaft (LH).................1
56 103-9740-01 Weldmt, Front Lift W/Lever(RH) ............1
57 1-523157 Washer, Spacer.....................................2
58 109-4995 Asm, Front Frame Spring ......................2
Exmark red touch up paint (spray paint – P/N 1-850337 - .6 oz liquid bottle – P/N 103-9140).
Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on spacer nut, Item #52.
V Includes frame weldment plus items #2, #31, #34, #39, #49, #51, #55, #56 and #57.
