FUEL GROUP
-11-
Item
Part No.
Description
Qty.
1 92-2379 Clamp, Fuel Line....................................14
2 3296-2 Nut, Nyloc #10-24..................................3
3 321-3 Screw, HH 1/4-20 x 5/8..........................1
4X 1-633023 Stud, Fuel Tank .....................................6
5 1-633349 Spring, Compression .............................6
6 1-643312 Clip, Loom .............................................1
7 1-643115 Tie, Cable 11.4 ......................................4
8 116-0973 Valve, Fuel Dual Flow............................1
9 1-805005 Washer, Lock 5/16 Heavy......................4
10 1-807513 Bolt, Carriage #10-24 x 1/2 ....................2
11 1-807533 Bolt, Carriage #10-24 x 5/8 ....................1
12 103-6564 Kit, Fuel Gauge......................................1
13 112-7836 Filter, Fuel..............................................1
14 103-1193 Clip, Loom Half......................................1
15 103-2595 Connector, Fuel 1/4 X 5/16 ....................1
16+ 116-0968 Fitting, Fuel Bulkhead............................4
103-2784 O-Ring ...................................................1
17 109-0299 Hose, Fuel Line 18”................................2
186 116-0141 Asm, Fuel Tank (LH)..............................1
19 32128-33 Nut, Whizlock 1/4-20..............................2
20 32128-20 Nut, Whizlock 5/16-18............................1
21W 109-2661 Screw, PPH #10-24 x 1/2.......................4
226 116-0142 Asm, Fuel Tank (RH).............................1
23 110-8806 Pump, Fuel ............................................1
24 110-4100 Hose, Fuel Line 43.5”.............................2
Item
Part No.
Description
Qty.
25 108-5928 Swivel, Cable Stop.................................1
26 109-0274 Hose, Fuel Line 16” ...............................1
27 110-9662 Hose, Fuel Line 32” ...............................1
28 3296-47 Nut, Nyloc 5/16-18 Thin.........................6
29 110-8817 Bracket, Pump Mount............................1
30 109-0308 Hose, Fuel Line 24” ...............................1
31 110-4114 Hose, Fuel Line 39” ...............................1
32 114-5062 Cap, Fuel (Bio-Diesel) ...........................2
33 1-303077 Clamp, Fuel Line ...................................1
34 109-7875 Asm, Control Panel W/Decals ...............1
35 3256-23 Washer, 5/16 SAE.................................13
36 109-6652 Cable, Throttle.......................................1
37 116-0290 Asm, Filter and Mount............................1
38 3256-14 Washer, #10 Std....................................1
39 3220-1 Nut, Jam 1/4-28.....................................2
40 110-6186 Hose, Fuel Line 30” ...............................1
41 110-0047 Hose, Fuel Line 2 3/8” ...........................1
42 110-4104 Hose, Fuel Line 11” ...............................1
43 104-8300 Nut, Nyloc 5/16-18 Flg...........................2
44 322-3 Screw, HH 5/16-18 x 3/4........................4
45 322-4 Screw, HH 5/16-18 x 7/8........................3
46 353-707 Adapter, 90° ..........................................2
47 2412-108 Clamp, Hose..........................................5
48 116-0289 Element, Fuel Filter ...............................1
49 321-8 Screw, HH 1/4-20 x 1 1/4.......................1
X Use Pro-Lock, Retaining type (Part No. 1-840023), .5cc tube on stud threads going into the tank.
W Snug fit only on slotted holes, Do Not Overtighten, tank must be able to expand.
+ Use Prolock, Nut type (Part No. 1-840022), .5ml tube on fuel fitting.
6 Includes tank, cap, fittings, and studs. LH tank also includes fuel gauge.
