MAIN FRAME GROUP
-9-
Item
Part No.
Description
Qty.
1 1-513658 Bumper..................................................2
2 1-633964-03 Stop, Park Brake....................................1
3 322-5 Screw, HH 5/16-18 x 1...........................6
4 323-39 Screw, HH 3/8-16 x 5.............................2
5 3296-29 Nut, Nyloc 5/16-18.................................6
6 3296-39 Nut, Nyloc 3/8-16...................................7
7 32128-20 Nut, Whizlock 5/16-18............................5
8 323-6 Screw, HH 3/8-16 x 1.............................10
9 3290-357 Nut, Whizlock 3/8-16..............................10
10 103-5519 Spring....................................................1
11 242-50 Nut, Lug 1/2-20 .....................................8
12 109-3157 Asm, Wheel & Tire.................................2
103-4963 Tire, 26x12-12 4 Ply...............................2
109-3156 Wheel ....................................................2
13
109-3984
Asm, Engine Deck (116-0573-03)
W/Decals...............................................
1
14 103-5161 Link, XP Seat Stop.................................2
15 107-1881 Kit, Knob................................................1
16V 116-1080 Seat, Suspension...................................1
109-3343 Kit, Spring and Saddle ...........................1
109-3344 Kit, Back Panel ......................................1
109-3345 Kit, Weight Adjust..................................1
17 1-653282-03 Stop, Seat..............................................2
18 107-1885 Kit, Weight Indicator...............................1
19 107-0075 Bushing..................................................1
20 109-2759 Link, XP Lower Seat Stop......................2
21 103-3666 Asm, Cubby...........................................1
22 32122-28 Screw, Truss HD #10-24 x 1..................4
23 3296-2 Nut, Nyloc #10-24..................................8
24 3256-4 Washer, 3/8 Std.....................................1
25 107-1880 Kit, Seat Track.......................................1
Item
Part No.
Description
Qty.
26 103-3790 Latch, Cubby Door.................................1
27 3290-500 Screw, PPH #10-24 x 5/8.......................2
28
109-2075 Asm, Console(103-8273-03) W/Decals..1
29 322-3 Screw, HH 5/16-18 x 3/4........................6
30 3256-23 Washer, 5/16 SAE.................................6
31 3296-42 Nut, Nyloc 1/4-20...................................2
32 3256-14 Washer, #10 Std....................................8
33 1-803075 Screw, Truss Head #10-24 x 3/4............2
34 98-5975 Washer, Spring Disc 3/8........................8
35 109-2394 U-bolt.....................................................2
36X 109-0060 Kit, XP ROPS........................................1
37 107-1883 Kit, Bottom Cushion...............................1
38 82-2190 Kit, Switch..............................................1
39 107-1887 Kit, Armrest............................................1
40 107-1884 Kit, Shock Absorber...............................1
41 107-1882 Kit, Back Cushion..................................1
42 110-0883 Kit, Seat Belt..........................................1
43 3212-4 Screw, HH 7/16-20 x 1.0........................2
44 1-603610 Washer, Spring Disc 7/16......................2
45 107-3155 Cotter, Hair Pin Double Loop.................2
46 325-13 Screw, HH 1/2-13 x 3 1/4.......................2
47Q 103-4553 Asm, Rops Fold Pin...............................2
48 32128-23 Nut, Hex Flange Side Lock 1/2-13 .........2
49 3296-73 Nut, Nyloc 1/4-20...................................2
50 109-2365 Bumper..................................................4
51 1-543963 Bumper, Rubber....................................1
52 109-9228 Kit, Seat Frame .....................................1
53 323-9 Screw, HH 3/8-16 x 2.............................1
54 103-5520 Latch, Seat ............................................1
55 103-7599-03 Guard ....................................................1
56 63-8410 Washer..................................................1
Exmark black touch up spray paint – Gloss black
Q Includes ROPS fold pin plus hairpin, item #45.
X Rollover protection frame is serviced as a complete assembly only. Includes complete ROPS frame, mounting
hardware, fold pivot and locking hardware, seat frame assembly item #52, and seat belt assembly item #42. Items
#51, #55, & #56 are not included.
V
Includes seat assembly plus tracks item #25, seat stops item #17, and seat wiring harness (item #5 pg. 25).
Does not include seat belt assembly item #42.
