MAINTENANCE
PARTS LIST
ITEM DESCRIPTION QTY.
NO.
1O-RING 1
2O-RING 1
3 VALVE BODY/RELIEF 1
4PISTON 1
5SPRING 1
6O-RING 1
7REGISTER 1
8 NUT, M16-1.5 1
9DEFLECTOR 1
10 O-RING 5
11 CENTERING RING 5
12 SPRING 5
13 SPACER 10
14 SCREW 5
15 CAP 20
16 SCREW 20
17 SCREW 4
18 CIRCLIP 1
19 WASHER 1
20 BUSHING 1
21 SPRING 1
22 BALL HOLDER 1
23 STEEL BALL D.5 3
24 STEEL BALL D.7 1
25 CAP 1
26 WASHER 1
27 SPACER 1
28 SPRING 1
29 SPACER 1
30 CENTERING RING 1
31 O-RING 15.10 X 2.70 X 1.5 1
32 PLUG 4
33 COPPER GASKET 14 X 20 X 15 4
34 REGISTER 4
35 SPRING 4
36 PISTON 4
37 VALVE BODY/RELIEF 4
38 O-RING 17.17 X 1.78 4
39 O-RING 4
40 PLUG 1
41 O-RING 17.17 X 1.78 1
42 O-RING 1
43 PLUG 6
44 SPRING 6
45 O-RING 11.11 X 1.78 6
46 BODY 6
47 PLUG 1
48 LEVER 2
49 RUBBER BELLOWS 2
50 HOUSING/LEVER 2
ITEM DESCRIPTION QTY.
NO.
51 O-RING 15.10 X 2.70 2
52 CENTERING RING 2
53 LEVER PIN 2
54 SCREW 8
55 O-RING 15.10 X 2.70 4
56 NUT 3
57 PLATE/JOYSTICK 1
58 SCREW 8
59 ASSEMBLY 2
60 ASSEMBLY 2
61 PIN 2
62 FLANGE 1
63 SCREW 6
64 NUT, M7 4
65 O-RING GASKET 2
66 RUBBER BELLOWS 2
67 SCREW 4
68 ARICULATION 2
69 NUT, M6 2
70 FLANGE 1
71 CENTERING RING 1
72 O-RING 15.60 X 1.78 1
73 PLATE/JOYSTICK 1
74 VALVE BLOCK 1
75 PLUG 1
*This parts list is provided to aid in maintenance and
servicing only. Service parts are sold in kits only.
