ASSEMBLY
60C 01/10 Assembly Section 3-13
© 2010 Alamo Group Inc.
ASSEMBLY
Dipperstick and Bucket Assembly Parts List
ITEM PART NO. QTY DESCRIPTION
1. 54477 1 DIPPERSTICK
2. 54485 1 LINK, BUCKET INNER 4 BAR
3. 54487 1 LINK, GUIDE
4. 54488 1 LINK, GUIDE PLATE
5. 54510 1 CYLINDER, BUCKET
6. * - BUCKET (2-7644) 9”
* - BUCKET (2-7645) 12”
* - BUCKET (2-7646) 16”
7. 41867-3 2 PIN, 1.00 X 5
8. 46632-4 2 PIN, 1.00 X 6.66
9. 41838-28 4 SCREW, CAP 5/16-18 X 2 GR5
10. 41840-2 4 NUT, LOCK 5/16-18
11. 45252-3 4 BUSHING, SLEEVE
12. 45252-1 2 BUSHING, SLEEVE
13. 6075-4 5 FITTING, GREASE 1/4-28
14. 42577-5 2 BUSHING, MACHINERY
15. 41903-13 2 PIN, COTTER 1/4 X 1.50
16. 44867-1 - TOOTH, BUCKET
17. 41703 - SHANK, BUCKET
