ASSEMBLY
Boom Assembly Parts List
ITEM PART NO. QTY DESCRIPTION
1. 54465 1 BOOM
2. 54489 1 CYLINDER, BOOM
3. 54503 1 CYLINDER, DIPPERSTICK
4. 47318 2 PIN, 1-1/4 X 6.62
5. 41838-54 2 SCREW, CAP 3/8-16 X 2.50 GR5
6. 41840-3 2 NUT, LOCK3/8-16
7. 41838-28 1 SCREW, CAP 5/16-18 X 2 GR5
8. 41840-2 1 NUT, LOCK 5/16-18
9. 6075-4 3 FITTING, GREASE 1/4-28
10. 6075-2 2 FITTING, GREASE 1/8 SELF TAP
11. 46632-5 1 PIN, 1 X 5.25
12. 6077-8 3 NUT, ELASTIC STOP 3/8
13. 6079-9 1 GROMMET, RUBBER
14. 53297 1 CLAMP
15. 13722 2 CLAMP
16. 41838-23 1 SCREW, CAP 3/8-16 X 1.50 GR5
17. 44908 1 DECAL, BOOM LOCK
18. 52154 2 DECAL, ALAMO SMC
19. 54686 2 DECAL, 60C BIG
