ASSEMBLY
60C 01/10 Assembly Section 3-5
© 2010 Alamo Group Inc.
ASSEMBLY
Mainframe Assembly Parts List
ITEM PART NO. QTY DESCRIPTION
1. 54712 1 CONSOLE W/ DECALS
2. 53717 1 COVER PLATE
3. 54457 2 STABILIZER
4. 53707 2 PAD, STABILIZER
5. 47272 2 CYLINDER STABILIZER
6. 44831 2 BUMPER, RUBBER
7. 54463 2 LOCK STABILIZER
8. 41838-100 2 SCREW, CAP 3/4-10 X 6.5 GR5
9. 6077-9 2 NUT, ELASTIC STOP 3/4-10
10. 41903-13 2 PIN, COTTER
11. 41902-3 2 PIN, CLEVIS
12. 31332-7 2 PIN, 1.00” X 4.12
13. 41838-28 2 SCREW, CAP 5/16-18 X 2 GR5
14. 46632-5 2 PIN, 1.00 X 5.25
15. 42502-8 8 WASHER, FLAT 3/8
16. 47046 2 BOLT, SHOLDER 3/8-16 X 1.00 GR5
17. 46303-6 6 TUBE, SPACER
18. 41838-17 6 SCREW, CAP 3/8-16 X 2.00 GR5
19. 41840-3 8 NUT, LOCK 3/8-16
20. 42502-7 4 WASHER, FLAT 5/16
21. 41840-2 4 NUT, LOCK 5/16-18
22. 6067-1 2 NUT SPEED
23. 41837-2 2 WASHER, LOCK 5/16
24. 41838-26 4 SCREW, CAP 5/16-18 X 0.75 GR5
25. 6075-4 6 FITTING, GREASE 1/4-28
26. 54464 1 COVER, SEAT BRACKET
27. 25820-6 1 ANTI SKID SURFACE
28. 41901-2 1 PIN, COTTER
29. 45970 1 DECAL, WARNING
30. 44907 1 DECAL, WARNING
31. 44895 2 DECAL, DANGER
32. 44896 1 DECAL, WARNING
33. 44897 2 DECAL, DANGER
34. 44898 1 DECAL, OPERATION
35. 44899 1 DECAL, OPERATION
36. 44900 1 DECAL, OPERATION
37. 44901 1 DECAL, OPERATION
38. 44909 1 DECAL, SWING LOCK
39. 48280 1 DECAL, UNIVERSAL ONE CALL
40. 52454 1 DECAL, ALAMO SMC
41. 54687 1 DECAL, 60C SMALL
42. 54427 1 MAINFRAME
43. 54884 2 BUMPER, 2” DIAMETER
44. 41838-95 2 SCREW, CAP 1/2-13 X 0.75 GR5
45. 41837-5 2 WASHER, LOCK 1/2
