Maintenance Instructions LUBRICATION
56
Ident Lubrication No.
No. Location Type Places
Ident Lubrication No.
No. Location Type Places
1 Deck Caster Wheel Fork Pivot Grease 2
2 Deck Caster Wheel Bearing Grease 2
3 Tee Gearbox, Deck Oil
* 1
4 Blade Drive Gearbox Oil
* 2
5 Universal Joint Shaft Assembly Grease
** 1
6 Pivot Assembly, Tilt-Up Deck Grease 4
7 Deck Support Arm Socket Grease 2
8 Body Hinge Point Oil 2
9 FSC Actuator Rod Pivot Pins Oil 2
10 FSC Lever Pivot Grease 1
11 FSC Lever Fork Grease 1
(Grease Slide Area)
12 (FSC) Friction Body Pivot Grease 1
13 Steering Lever Pivot Grease 4
14 Deck Support Arm Pivot Grease 2
15 Deck-to-PTO Coupling Grease 1
(Grease Slide Area)
16 Universal Joint Tube Assembly Grease
** 1
17 Universal Joint Quick Connect Grease 1
Spline (Grease Slide Area)
18 Parking Brake Lever Grease 1
19 Gear Axle Oil
*** 2
20 Belt Tightener Pivot, Grease 1
Jackshaft Drive
21 Throttle Control Cable Ends Oil 2
22 Clutch Actuator Push Rod Grease 2
23 PTO Clutch Lever Pivot Grease 1
24 Belt Tightener Pivot, Grease 1
PTO Clutch
25 Brake Actuator Rod and Brake Oil 3
Band Pivot Pins (Clevis)
26 Brake Actuator Pivot Grease 1
27 Catcher Hinge Point Oil 2
28 Rear Wheel Bearings Grease 2
29 Engine Oil Oil
*** 1
30 Choke Control Cable Ends Oil 2
(Models MT and MTL only)
31 Belt Tightener Pivot, Grease 1
Blower Drive (GHS Model Only)
32 Belt Tightener Pivot, Grease 1
Ground Drive
33 PTO Gearbox Dipstick Oil
*** 1
34 Hydrostatic Drive Oil
*** 2
35 Choke Control Pivot Oil 1
(Models MT and MTL only)
36 Throttle Control Pivot Oil 1
* Gearboxes are permanently lubricated and
sealed requiring no scheduled lubrication.
Oil level should be checked only when an oil
leak is noted. Refer to Mower Deck Gear-
box Lubrication in this section.
** Grease every eight (8) hours.
*** Refer to Gear Axle Lubrication, Engine
Oil, Tractor PTO Gearbox Lubrication, and
Hydrostatic Transmission Fluid in this sec-
tion.
NOTE: DGHS42 Tilt-Up Deck is shown for reference.
For other Deck Lubrication Points, Refer to
Deck and Carrier Frame Illustrated Parts
Manual.
