ITEM PA RT DESCRIP TION NO.
NO. NO. REQ’D
ITEM PART DESCRIPTIO N NO.
NO. NO. REQ’D
Use only genuine Walker
®
replacement parts. Effective Date 06-01-01
84
SNOWBLOWER DRIVE COMPONENTS
Gearbox Assembly
1 I193 Double Lip Seal 2
2 NS Breather, 3/8 NPT & O-Ring (Comer) 1
(RAD 661185)
NS Pressure Plug, 1/8 NPT (Usimax) 1
(RAD 654927)
3 O/L M8 Hex Nut 6
4 I178 Spring Pin, Casing 2
5 NS Cap (RAD 661150) 1
6 I182 Bearing, Gearbox 2
7 NS Pinion Gear (RAD 661160) 1
8 I198 Shim, Pinion Shaft 1
9 I194 Oil Seal 1
10 I199 Shaft, Gearbox 1
11 O/L M8 x 40 Hex Bolt 2
12 O/L M8 x 65 Hex Bolt 4
13 NS Casing Ello (RAD 661145) 1
14 NS Oil Plug, 1/4 (Comer) (RAD 661972) 1
NS Plug, 1/8 NPT (Usimax) (RAD 656090) 1
15 I195 Bearing 2
16 I181 Shim, Gearbox 2
17 NS Gear (RAD 661159) 1
18 NS Plug, 3/8 NPT & O-Ring (Comer) 1
(RAD 659847)
NS Plug, 1/8 NPT (Usimax) (RAD 656090) 1
19 NS Casing (RAD 661142) 1
Driveline and Auger Components
20 6671 Driveline Male Portion Assembly 1
(Includes Items # 25-29)
21 I394 Decal, Rotating Auger 2
22 5800 Decal, Walker Mower (4 x 7-1/2) 1
23 NS Decal, Check Oil Level (RAD 655683) 1
24 NS Decal, Lubricate Chain (RAD 657804) 1
25 6671-4 Male Shaft and Yoke Assembly 1
26 6671-3 Bearing Retainer 1
27 6671-2 Nylon Bearing 1
28 6671-1 Outer Shield 1
29 I395 Decal, Rotating Driveline 1
30 5609 Spindle Bearing & Collar 2
(Includes Item # F309)
31 O/L 5/16-NC Hex Nut 12
32 O/L 5/16 Lock Washer 12
33 I120 Bearing Flange 2
34 O/L 5/16-NC x 3/4 Carriage Bolt 3
35 NS Decal, Use Shear Bolts (RAD 657346) 1
36 I103 Bushing 2
37 O/L 5/16-NC x 2 GR 8 Hex Bolt 1
38 I109 Auger, LH 1
39 I111 5/16-18 x 2-1/4 Shear Bolt Lock & Nut 2
40 I128 Shear Bolt Bushing 4
41 I113 Bearing Flange 2
42 O/L 3/8 ID Flat Washer 2
43 5830 Grease Fitting 2
44 I101 Gearbox (Comer) 1
(Includes Items # 1-19)
NS Gearbox (Usimax) (RAD 663030) 1
NS Seal Kit (RAD 665775) 1
45 NS Output Shaft (RAD 657286) 1
46 I130 Woodruff Key 1
47 I110 Auger, RH 1
48 O/L 5/16-NC x 3/4 Hex Bolt 8
49 NS Gearbox Support Bracket (RAD 657332) 1
50 I105 1/4-20 x 1 Shear (w/Locknut) 1
51 I104 Fan Adaptor Shear Plate 1
52 I102 Fan Assembly 1
Fasteners
F309 1/4-28 x 1/4 Set Screw 3
NOTE: Decals are illustrated in greater detail in the Owner’s sec-
tion of this manual. Refer to SAFETY, CONTROL, AND
INSTRUCTION DECALS in Safety Instructions, Page
17.
NOTE: All NS items are listed with a RAD Part Number (e.g., RAD
657383), and are not sold by Walker Manufacturing. To
order these items, contact:
RAD Technologies Inc.
2835, Chemin de l’Aéroport
Thetford Mines (Québec)
G6G 5R7 CANADA
1-418-338-4499
