Removal and Storage Instructions
70
Detach Debris Blower from Implement Hitch
Removing Implement Hitch from Tractor
IMPORTANT: Detach any attached implement
from the hitch before detaching the hitch
from the tractor. Refer to the instructions for
REMOVAL of Dozer Blade, Rotary Broom,
Two-Stage Snowblower, or Debris Blower in
this section.
1. Park the tractor on a level surface and lower the
implement hitch.
2. Unplug the male connector on the implement lift
wiring harness from the female connector on
the linear actuator.
3. Remove the hitch pins from each support arm
and slide the implement hitch off the support
arms.
Detach Implement Hitch from Tractor
END OF SEASON STORAGE
Implement Hitch
1. Clean the implement hitch thoroughly.
2. Repaint all parts from which paint has worn.
NOTE: Rustproofing or painting every year
will prolong the life of the hitch components
and moving parts.
3. When the implement hitch is dry, lubricate all
moving parts. Apply lubricant liberally to all ex-
posed surfaces to protect against rust.
4. List the replacement parts that will be needed
before the next season.
5. Store the hitch in a dry place.
Dozer Blade
1. Clean the dozer blade thoroughly.
2. Repaint all parts from which paint has worn.
WARNING
DO NOT attempt to remove the implement
hitch with the tractor engine running. Dis-
engage the PTO clutch, stop the engine
and remove the ignition key. Wait for all
movement to stop before getting off the
seat.
To prevent accidental engine starting, dis-
connect the fuel solenoid wire [diesel en-
gines] or the spark plug wire(s) [gasoline
engines].
PTO Shaft
Hitch Locking
Lever
Quick Hitch
Latch
Parking
Stand
WARNING
NEVER store the tractor with fuel in the
fuel tank inside a building where open
flames or sparks are present. Allow the
engine to cool before storing in any
enclosure.
Support Arms
