42” MOWING DECK
DECK IDLER
NOT SHOWN
DESCRIPTION PART # QTY
5/16-18 X 3/4 Serr Flg Bolt NB596 2
5/16-18 Serrated Flange Nut NB170 2
Roller Bracket (12) Mounting Hardware
16
17
18
19
6
21
22
25
Item # Description Part #
1 Grass Chute Weldment 3757TK
2 Grass Chute Mount 6030TK
3 5/16-18 X 8 1/2 HCC GR2 ZP NB136
4 Torsion Spring - Bent Leg 9100
5 Deck Weldement 3762TK
6 5/16-18 X 3/4 Serr Flg Bolt NB596
7 Pulley Cover 3743
8 5/16-18 Serrated Flange Nut NB170
9 Sway Bar Left 3665
Sway Bar Right 3664
10 1/8 X 1 Cotter Pin NB126
11 Lift Bracket 3738TK
12 Front Roller Bracket 4018TK
13 3/8-16 X 5 1/2 GR5 ZP NB575
14 Anti-Scalp Roller AS001
15 3/8-16 Nyloc Nut NB182
16 3/8-16 X 2 1/2 HCC GR5 ZP NB221
17 3/8 SAE Washer NB272
18 Idler Pulley B527
19 Idler Bushing 6037
20 Idler Spacer 6040
21 Seat Hinge 3808TK
22 5/16-18 Nyloc Nut NB181
23 5/16-18 Eye Bolt NB315
24 Two Speed Spring TZ2S
25 3/8-16 2-Way Lock Nut NB280
26 Idler Pulley 7509
27 3/8-16 X 2 HCC GR5 ZP NB198
28 Idler Weldment 3850TK
29 5/16-18 Jam Nut NB173
30 Washer Bellvl. 413 X .945 X .118 NB607
8
29
23
24
27
17
26
30
28
20
27
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
