LEVELING THE MOWER DECK
1. Position unit on a smooth level surface.
2. For side to side leveling, measure the distance from the floor to the bottom edge at the
rear of the deck. The measurement should be equal within 1/16 inch side to side.
Adjustment can be made by loosening locking nut on rear eyebolt hangers and adjusting
up or down as needed.
3. For front to rear pitch adjustment, loosen locking nut on front eyebolt and adjust up or
down as needed. Proper pitch measurement is 1/8” to 1/4”
lower at the front of the deck.
Distance should be
equal on both rear sides.
Front of deck should be
slightly lower.
Ground
Front of Mower
13
