FRAME for 50” Mower
Item # Description Part #
1 Beverage Retainer 3643TK
2 Fender-Right 3012TK
Fender-Left 3011TK
3 Fender Mount 5142TK
4 Battery Box 3696TK
5 5/16-18 X 3/4 Serr Flg Bolt NB596
6 Transmission Mount 3835TK
7 Upper Motor Base 3777TK
8 5/16-18 Serrated Flange Nut NB170
9 Rear Cover 3711TK
10 Transmission Fan Cover-Right 3806TK
Transmission Fan Cover-Left 3712TK
11 Bumper Weldment 3778TK
12 5/16-18 X 1 1/2 Flge Serr. Bolt NB254
13 5/16-18 X 1 3/4 Flge Serr Bolt NB515
14 Rear Hanger Bracket 3264TK
15 1/2-13 2-Way Jam Lock Nut NB121
16 Front Axle-Weldment 3401TK
17 1/2-13 X 2 1/2 HCC GR5 ZP NB510
Item # Description Part #
18 13/16 X 1 1/4 X 1/8 Washer NB195
19 Caster Fork 665TK
20 5/8 ID X 1 OD 10 GA Washer NB178
21 5/8-11 X 7 HCC GR5 ZP NB624
22 Wheel Spacer 3395
23 Front Tire 3010
24 5/8-11 2 Way Lock Jam Nut NB595
25 Bearing B98
26 5/16-18 X 2 1/2 HCC GR5 ZP NB138
27 3/4-16 Jam Nylok Nut NB122
28 Kick Plate 3396TK
29 Access Plate 3397TK
30 Seat Base Weldment 3719TK
31 Belt Snubber 3819TK
32 5/16-18 X 1/2 Serr. Flg Bolt NB252
33 1/4-20 Flange Nut NB524
34 1/4-20 X 3/4 GR5 ZP NB250
35 Choke Mount 3810TK
1
2
4
6
7
33
5
3
34
9
10
11
13
12
13
14
8
17
15
16
18
19
20
21
22
23
20
22
25
24
26
18
27
28
29
30
8
5
25
32
8
35
31
SEE DETAIL
PAGE 19 & 20
23
