P2201 (22 KW) P2701 (27 KW) P3201 (32 KW)
Rated Wattage - (Standby)
@1.0 PF LPG *
22,000 27,000 32,000
Rated Wattage - (Standby)
@1.0 PF NG *
19,800 24,300 28,800
Voltage 120/240 volts 120/240 volts 120/240 volts
Rated Current 184/92 amps LPG 224/112 amps LPG 255/133 amps LPG
Frequency 60 HZ 60 HZ 60 HZ
Power Factor 1.0 1.0 1.0
Max. Ambient Temp Rise 105°C 105°C 105°C
Insulation class H H H
Engine GM 3.0 L GM 3.0 L GM 3.0 L
Engine Type Water cooled inline (4 cyliners) Water cooled inline (4 cyliners) Water cooled inline (4 cyliners)
RPM 1800 1800 1800
Displacement cc (c.i.d) 2966 (181) 2966 (181) 2966 (181)
Bore X Stroke mm (inches) 101.60 x 91.44 (4.00 x 3.60) 101.60 x 91.44 (4.00 x 3.60) 101.60 x 91.44 (4.00 x 3.60)
Compression Ratio 10:5:1 10:5:1 10:5:1
Valve arrangement Overhead valve Overhead valve Overhead valve
Governor Electronic, Isochronous Electronic, Isochronous Electronic, Isochronous
Ignition system Solid State Distributor Solid State Distributor Solid State Distributor
Starter 12vdc, Solenoid Shift 12vdc, Solenoid Shift 12vdc, Solenoid Shift
Alternator 12vdc 12vdc 12vdc
Oil Capacity (w/o filter) 4 qts (3.8L) 4 qts (3.8L) 4 qts (3.8L)
Oil Capacity (with filter) 5 qts (4.7L) 5 qts (4.7L) 5 qts (4.7L)
Oil Filter PF-25 or equivalent PF-25 or equivalent PF-25 or equivalent
Radiator capacity
Shipped with 50/50 mix of
water and propylene glycol
antifreeze.
Shipped with 50/50 mix of
water and propylene glycol
antifreeze.
Shipped with 50/50 mix of
water and propylene glycol
antifreeze.
Spark plug AC Delco R45TS AC Delco R45TS AC Delco R45TS
Battery
BCI Group 34, minimum
750 CCA
BCI Group 34, minimum
750 CCA
BCI Group 34, minimum 750
CCA
Air filter 019-0255 019-0255 019-0255
Minimum Content
Requirements for Natural Gas
(NG) **
1000 BTU’s per cubic foot 1000 BTU’sper cubic foot 1000 BTU’sper cubic foot
Minimum Content
Requirements for Liquid
Propane Vapor (LPG) **
2520 BTU’sper cubic foot 2520 BTU’sper cubic foot 2520 BTU’s per cubic foot
Consumption at Full Load for
Natural Gas (NG)
280 cubic feet per hour 304 cubic feet per hour 315 cubic feet per hour
Consumption at Full Load for
Liquid Propane Vapor (LPG)
3.44 gallons per hour 3.71 gallons per hour 3.99 gallons per hour
Dimensions (see next page
for installation drawing)
66”L x 35”W x 41”H 66”L x 35”W x 41”H 66”L x 35”W x 41”H
Shipping Weight 1300 1300 1300
Normal Operating Range -20°F (-28.8°C) to 104°F (40°C)
* Note: Rated wattage is specified at sea level, 60°F ambient temperature, and propane fuel (with 2500 BTU/cuft). Rated wattage decreases
approximately 3.5% for each 1000ft above sea level and approximately 1% for each 10°F above 60°F ambient temperature.
** Fuel supply pressures must be between 4 oz (6” w.c.) and 6 oz (11” w.c.) at inlet to the unit.
