North Star 13000 PTOG Portable Generator User Manual



2
SPECIFICATIONS
Item Number #165929
Maximum Output 13000 Watts (W)
Continuous Output 12000 Watts (W)
Voltage 120 / 240 Volt (V)
Phase Single phase (4-wire)
Frequency 59.0-63.0 Hertz (Hz)
Power Factor 100 %
Minimum PTO HP 24 HP at 540 RPM
Input Shaft 1 3/8” Diameter, 6 spline
120V Receptacle (2) 20 Amp (A) duplex (NEMA 5-20R)
30 Amp (A) twistlock (NEMA L5-30R)
120/240V Receptacle 50 Amp (A) Straight blade (NEMA 14-50R)
Circuit Breaker (2) 20 Amp (A) thermal, push to reset style
30 Amp (A) thermal, push to reset style
(2) 40 Amp (A) thermal, push to reset style
Gear Box
Gear Ratio 1:7
Gear Oil SAE 80W-90
Oil Capacity .86 Qt. (.82 L)
Dimensions
Length 28.38” (72.1 cm)
Width 14.25” (36.2 cm)
Height 12.50” (31.1 cm)
Gross Weight 127 lb. (57.7kg)
ANSI SAFETY DEFINITIONS
DANGER indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury. This signal word is to be limited to the
most extreme situations.
WARNING indicates a potentially hazardous situation which, if not avoided,
could result in a death or serious injury.
CAUTION indicates a potentially hazardous situation, which if not avoided,
may result in minor or moderate injury. It may also be used to alert against
unsafe practices.
