TLG-12SPX — PARTS AND OPERATION MANUAL (STD) — REV. #4 (03/08/05) — PAGE 117
ISUZU 3LB1 — TIMING CHAIN CASE ASSY.
TIMING CHAIN CASE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 8970456175 FLYWEIGHT 1
5 8970849771 SLEEVE.......................................1 ......................APR. 1992 TO MAR. 1996
8971474890 SLEEVE.......................................1 ......................APR. 1996~
6A 9081608500 LEVER SHAFT 1
6B 9081605450 LEVER SHAFT 1
6C 8970164460 LEVER SHAFT 1
7 8971176720 COVER ........................................1 ...................... APR. 1992 TO JUN. 1996
8971062740 COVER ........................................1 ...................... JUL. 1996 TO JAN. 1997
8971617450 COVER ........................................1 ...................... FEB. 1997~
16 1079470020 LEVER PIN 1
18 8970346393 PLATE .........................................1 ...................... APR. 1992 TO JUN. 1996
8971485500 PLATE .........................................1 ...................... JUL. 1996~
21 5095031320 GASKET SCREW 2
22A 9091114060 NUT 3
22B 9091104060 NUT 1
24 5094000480 NUT 1
25 5156690021 CAP 1
27 8970493280 LEVER 1
28 8971059061 LEVER .........................................1 ......................APR. 1992 TO JUN. 1996
8971605721 LEVER.........................................1 ...................... JUL. 1996~
29 1096230550 GASKET 2
30 8970169400 SPRING 1
31 5095031350 WASHER 2
32 9091105080 NUT 1
34 5157292391 EYE 1
35 987109759 MAIN SPRING 1
36 8970843250 START SPRING 1
37 8970169361 IDLE SPRING 1
39 8971097751 ANGLEICH KIT 1
40 8941304380 NUT 1
43 8970164492 LEVER 1
44 8970646881 COVER GASKET 1
45 8943695450 GEAR CASE BUSHING 1
46A 0280806200 BOLT 4
46B 0280806140 BOLT 1
46C 8970728300 BOLT 1
47 1157390020 LEAD SEAL 2
48 8913254460 LEAD SEAL WIRE 2
49 1096050190 COVER PLUG 1
50 8970345945 GUIDE LEVER 1
52 8971122650 GUIDE PIECE .............................1 ...................... REPLACES 8970718062
53 1097470020 GUIDE LEVER PIN 1
54 8971059100 TENSION LEVER 1
