Specifications
Specifications
Specifications
Engine 225D LC
Manufacturer and Model . . . . . . . . . . . . . . . . . . . Isuzu AI-4HK1XYSA-02
Non-Road Emission Standards . . . . . . . . . . . . . . . EPA Tier 3/EU Stage IIIA
Net Power (ISO9249) . . . . . . . . . . . . . . . . . . . . . . 159 hp (118 kW) @ 2,000 rpm
Cylinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Displacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 325 cu. in. (5.2 L)
Aspiration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . turbocharged, intercooled
Off-Level Capacity . . . . . . . . . . . . . . . . . . . . . . . . 70% (35 deg.)
Cooling
Direct-drive, suction-type fan
Powertrain
Two-speed propel with automatic shift
Travel Speed (maximum)
Low . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.2 mph (3.5 km/h)
High . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.4 mph (5.5 km/h)
Hydraulics
Open center, load sensing; auxiliary hydraulic flow adjustable through monitor
Main Pumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 variable-displacement axial-piston pumps
Maximum Rated Flow . . . . . . . . . . . . . . . . . . . 2 x 56.0 gpm (2 x 212 L/min.)
Pilot Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . one gear
Maximum Rated Flow . . . . . . . . . . . . . . . . . . . 7.9 gpm (30 L/min.)
Pressure Setting . . . . . . . . . . . . . . . . . . . . . . . 570 psi (3930 kPa)
System Operating Pressure
Implement Circuits . . . . . . . . . . . . . . . . . . . . . 4,980 psi (34 336 kPa)
Travel Circuits . . . . . . . . . . . . . . . . . . . . . . . . 4,980 psi (34 336 kPa)
Swing Circuits . . . . . . . . . . . . . . . . . . . . . . . . 4,410 psi (30 406 kPa)
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pilot levers, short stroke, low effort; hydraulic pilot controls with shutoff lever
Cylinders
Heat-treated, chrome-plated, polished cylinder rods; hardened-steel (replaceable bushings) pivot pins
Bore Rod Diameter Stroke
Boom (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.72 in. (120 mm) 3.35 in. (85 mm) 49.61 in. (1260 mm)
Arm (1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.31 in. (135 mm) 3.74 in. (95 mm) 58.10 in. (1475 mm)
Bucket (1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.53 in. (115 mm) 3.15 in. (80 mm) 41.73 in. (1060 mm)
Electrical
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 x 12 volt
Reserve Capacity . . . . . . . . . . . . . . . . . . . . . . . . . 180 min.
Alternator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 amp
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . halogen (one mounted on boom, one mounted on frame)
Undercarriage
Planetary final drives with axial piston motors
Carrier Rollers (per side) . . . . . . . . . . . . . . . . . . . . 2
Track Rollers (per side) . . . . . . . . . . . . . . . . . . . . . 8
Shoes (per side) . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Drawbar Pull. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45,636 lb. (20 719 kg)
Track
Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . hydraulic
Guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . front and center
Chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . sealed and lubricated
