16–17
Lift Capacities (continued) 135D
Boldface italic type indicates hydraulic-limited capacities; lightface type indicates stability-limited capacities, in lb. (kg). Ratings at bucket lift hook; machine equipped with
0.37-cu.-yd. (0.28 m
3
) bucket, 15-ft. 1-in. (4.6 m) boom, and standard gauge, and situated on firm, uniform surface. Total load includes weight of cables, hook, etc. Figures
do not exceed 87% of hydraulic capacities or 75% of weight needed to tip machine. All capacities are based on SAE J1097.
Load Point 5 ft. (1.52 m) 10 ft. (3.05 m) 15 ft. (4.57 m) 20 ft. (6.10 m) 25 ft. (7.62 m)
Height Over Front Over Side Over Front Over Side Over Front Over Side Over Front Over Side Over Front Over Side
With 9-ft. 11-in. (3.01 m) arm and 28-in. (700 mm) shoes, with 8-ft. 10-in. (2.69 m) blade on ground
20 ft. (6.10 m) 5,129 (2326) 5,129 (2326) 3,764 (1707) 3,764 (1707)
15 ft. (4.57 m) 5,342 (2423) 5,342 (2423) 5,603 (2541) 5,326 (2416)
10 ft. (3.05 m) 5,477 (2484) 5,477 (2484) 6,709 (3043) 6,709 (3043) 6,215 (2819) 5,158 (2340) 4,011 (1819) 3,405 (1544)
5 ft. (1.52 m) 9,350 (4241) 7,750 (3515) 7,236 (3282) 4,889 (2218) 5,504 (2497) 3,308 (1500)
Ground Line 10,793 (4896) 10,793 (4896) 11,321 (5135) 7,200 (3266) 8,149 (3696) 4,631 (2101) 5,967 (2707) 3,199 (1451)
–5 ft. (–1.52 m) 6,419 (2912) 6,419 (2912) 15,472 (7018) 13,100 (5942) 11,909 (5402) 6,925 (3141) 8,453 (3834) 4,472 (2028)
–10 ft. (–3.05 m) 14,078 (6386) 14,078 (6386) 16,229 (7361) 13,213 (5993) 10,957 (4970) 6,897 (3128) 7,628 (3460) 4,462 (2024)
–15 ft. (–4.57 m) 11,461 (5199) 11,461 (5199) 7,798 (3537) 7,114 (3227)
With 8-ft. 3-in. (2.52 m) arm and 20-in. (500 mm) rubber crawler pads, without blade
20 ft. (6.10 m) 6,263 (2841) 6,263 (2841)
15 ft. (4.57 m) 6,368 (2888) 6,368 (2888) 6,073 (2755) 4,627 (2099)
10 ft. (3.05 m) 9,119 (4136) 9,119 (4136) 7,951 (3607) 7,333 (3326) 6,254 (2837) 4,490 (2037)
5 ft. (1.52 m) 9,637 (4371) 6,749 (3061) 5,999 (2721) 4,254 (1930)
Ground Line 9,128 (4140) 6,293 (2854) 5,766 (2615) 4,038 (1832)
–5 ft. (–1.52 m) 6,904 (3132) 6,904 (3132) 16,795 (7618) 11,688 (5302) 8,921 (4046) 6,109 (2771) 5,647 (2561) 3,927 (1781)
–10 ft. (–3.05 m) 14,858 (6739) 11,881 (5389) 8,966 (4067) 6,149 (2789) 5,712 (2591) 3,987 (1808)
–15 ft. (–4.57 m) 5,738 (2603) 5,738 (2603)
With 9-ft. 11-in. (3.01 m) arm and 20-in. (500 mm) rubber crawler pads, without blade
20 ft. (6.10 m) 5,129 (2326) 5,129 (2326) 3,764 (1707) 3,764 (1707)
15 ft. (4.57 m) 5,342 (2423) 5,342 (2423) 5,603 (2541) 4,691 (2128)
10 ft. (3.05 m) 5,477 (2484) 5,477 (2484) 6,709 (3043) 6,709 (3043) 6,215 (2819) 4,522 (2051) 4,011 (1819) 2,917 (1323)
5 ft. (1.52 m) 9,350 (4241) 6,838 (3102) 6,009 (2726) 4,254 (1930) 4,058 (1841) 2,820 (1279)
Ground Line 10,793 (4896) 10,793 (4896) 9,137 (4144) 6,288 (2852) 5,731 (2600) 3,995 (1812) 3,942 (1788) 2,711 (1230)
–5 ft. (–1.52 m) 6,419 (2912) 6,419 (2912) 15,472 (7018) 11,488 (5211) 8,829 (4005) 6,013 (2727) 5,559 (2522) 3,837 (1740)
–10 ft. (–3.05 m) 14,078 (6386) 14,078 (6386) 16,229 (7361) 11,601 (5262) 8,798 (3991) 5,985 (2715) 5,549 (2517) 3,827 (1736)
–15 ft. (–4.57 m) 11,461 (5199) 11,461 (5199) 7,798 (3537) 6,203 (2814)
With 8-ft. 3-in. (2.52 m) arm and 20-in. (500 mm) rubber crawler pads, with 8-ft. 2-in. (2.49 m) blade
20 ft. (6.10 m) 6,263 (2841) 6,263 (2841)
15 ft. (4.57 m) 6,368 (2888) 6,368 (2888) 6,073 (2755) 5,061 (2296)
10 ft. (3.05 m) 9,119 (4136) 9,119 (4136) 7,951 (3607) 7,951 (3607) 6,859 (3111) 4,925 (2234)
5 ft. (1.52 m) 10,242 (4646) 7,372 (3344) 7,760 (3520) 4,688 (2126)
Ground Line 11,825 (5364) 6,917 (3137) 8,477 (3845) 4,472 (2028)
–5 ft. (–1.52 m) 6,904 (3132) 6,904 (3132) 16,795 (7618) 12,791 (5802) 11,921 (5407) 6,732 (3054) 8,471 (3842) 4,362 (1979)
–10 ft. (–3.05 m) 14,858 (6739) 12,984 (5889) 10,399 (4717) 6,772 (3072) 6,917 (3137) 4,422 (2006)
–15 ft. (–4.57 m) 5,738 (2603) 5,738 (2603)
With 9-ft. 11-in. (3.01 m) arm and 20-in. (500 mm) rubber crawler pads, with 8-ft. 2-in. (2.49 m) blade on ground
20 ft. (6.10 m) 5,129 (2326) 5,129 (2326) 3,764 (1707) 3,764 (1707)
15 ft. (4.57 m) 5,342 (2423) 5,342 (2423) 5,603 (2541) 5,125 (2325)
10 ft. (3.05 m) 5,477 (2484) 5,477 (2484) 6,709 (3043) 6,709 (3043) 6,215 (2819) 4,957 (2248) 4,011 (1819) 3,250 (1474)
5 ft. (1.52 m) 9,350 (4241) 7,461 (3384) 7,236 (3282) 4,688 (2126) 5,504 (2497) 3,154 (1431)
Ground Line 10,793 (4896) 10,793 (4896) 11,321 (5135) 6,912 (3135) 8,149 (3696) 4,430 (2009) 5,967 (2707) 3,045 (1381)
–5 ft. (–1.52 m) 6,419 (2912) 6,419 (2912) 15,472 (7018) 12,591 (5711) 11,909 (5402) 6,636 (3010) 8,453 (3834) 4,271 (1937)
–10 ft. (–3.05 m) 14,078 (6386) 14,078 (6386) 16,229 (7361) 12,703 (5762) 10,957 (4970) 6,609 (2998) 7,628 (3460) 4,261 (1933)
–15 ft. (–4.57 m) 11,461 (5199) 11,461 (5199) 7,798 (3537) 6,826 (3096)
