PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY
1 31104488 Upper handle assy. 1
1.1 34135486 Foam grip 1
1.2 33310470-2 Upper handle 1
2 32207115 Washer 6
3 33323250-1 Stop sheet 1
4 3220439 Lock nut M5 1
5 32208234A Screw M5x30 1
6 31107486-1 Motor engagement box assy. 1
6.1 34136486 Start button 1
6.2 33401229 Spring 1
6.3 34122486 Upper cover, motor engagement box 1
6.4 34140486 Compressor 1
6.5 3220735N Screw ST3x8-C 3
6.6 31901250 Start cable (short) 1
6.7 33318250 Tension spring 1
6.8 34118250 Block 1
6.9 32204250 Screw M3x20 1
6.10 33317250 Slide block 1
6.11 33316250 Torsion spring 1
6.12 33315250 Spring 1
6.13 3221305 Nut M3 1
6.14 31901486 Start cable (long) 1
6.15 34121486 Lower cover, motor engagement box 1
6.16 32204113D Screw ST4.2x20-C 4
7 33305469-3 Motor bail 1
8 34106467-1 Knob 2
9 31102467-2 Cam lock assy. 4
10 33324250 Cord guide 1
11 33332250 Spring 1
12 32204113D Screw ST4.2x20-C 4
13 34119486 Upper cover, switch box 1
14 34114250 Slide block, switch box 1
15 36301289 Switch 1
16 32201572 Screw ST4.2x14 4
17 32202517 Screw ST4x10 5
18 33314486 Switch box bracket 1
19 33315486 Lower handle 1
20 34135469A Cord guide 1
21 31104975 40V 146Wh battery pack 1
22 31103976 40V 73Wh battery pack 1
23 31201470 Key 1
24 34903250 knit 15 cm
