26
MAINTENANCE
• Replace the blade insulator and spacer, then thread the blade nut on the shaft and finger
tighten.
NOTE: Make certain all parts are replaced in the exact order in which they were removed.
• For the BLADE I, torque the blade nut down counterclockwise using a torque wrench (not
provided) to ensure the bolt is properly tightened. For the BLADE II, torque the blade nut
down clockwise using a torque wrench (not provided) to ensure the bolt is properly tightened.
The recommended torque for the blade nut is 350-400 in. lbs.
Fig. 17
BLADE IBLADE II
Motor
assembly
Blade posts
Blade insulator
Spacer
Blade nut
Blade nut
Spacer
Blade insulator
