INSTALLING THE GRASS CATCHER (FOR REAR BAGGING OPERATION) (See
Figure 5-6)
NOTE: When using the grass catcher, do not install the mulching plug.
• Remove key and battery pack.
• Lift the rear discharge door.
• Lift the grass catcher by its handle and place under the rear discharge door so that the hooks
on the grass catcher are seated onto the slots on the mower housing.
• Release the rear discharge door.
• Reinstall key and battery pack when you are ready to mow.
ASSEMBLY INSTRUCTIONS
Fig. 5
Fig. 6
Grass catcher handle
Rear discharge
opening
Slots
Hooks
Rear door
Door rod
15
Hooks
Slots
