CASTER WHEEL ASSEMBLY
-12-
Item Part No. Description Qty.
1 1-543509 Cone, Bearing Tapered Roller ............ 2
2 1-543511 Seal, Grease ....................................... 1
3 116-1963-01 Wld, Caster Fork ................................. 1
4 1-633508 Washer, Spring Disc ........................... 3
5 116-1949 Asm, Wheel And Tire W/Axle .............. 1
5:1 103-2768 Guard, Seal ......................................... 2
5:2:1 1-633585 Bearing, Cone Tapered Roller ............ 2
Item Part No. Description Qty.
5:2:2 103-0063 Seal, Double Lip .................................
.
2
5:2:3 103-3051 Spacer, Nut .........................................
.
2
5:2:4 103-3155 Axle, Caster ........................................
.
1
5:3 325-42 Screw, HH 1/2-13 x 8 .........................
.
1
5:4 3296-23 Nut, Nyloc 1/2-13 ................................
.
1
6 103-4882 Cap-Grease ........................................
.
1
7 3296-51 Nut, Nyloc 3/4-10 ................................
.
1
Exmark red touch up paint (spray paint – P/N 1-850337 - .6 oz liquid bottle – P/N 103-9140).
Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on spacer nut, item 5:2:3.
.
