Product Overview
Torque Requirements
Bolt Location
Torque
Cutter Housing Spindle
Nut
140-145 ft-lb
(190-197 N-m)
Blade Mounting Bolt
(lubricate with anti-seize)
55-60 ft-lb (75-81 N-m)
Engine Deck/Mower
Deck Support Mount
Bolts
30-35 ft-lb (41-47 N-m)
Anti-Scalp Roller Nyloc
Nut See Figure 9
30-35 ft-lb (41-47 N-m)
Anti-Scalp Roller Whizlock
Nut See Figure 9
30-35 ft-lb (41-47 N-m)
Engine Mounting Bolts
15-20 ft-lb (20-27 N-m)
Wheel Lug Nuts
90-95 ft-lb (122-129 N-m)
Wheel Hub Slotted Nuts minimum 100 ft-lb
(136 N-m)
Wheel Motor Mounting
Bolts
30-35 ft-lb (41-47 N-m)
Product Overview
Figure 3
1. Park Brake Lever
3. Fuel Cap
2. Controls 4. Height-of-Cut Pins
16
