Operation
Product Overview
Figure 3
1. Controls 4. ECS Handles
2. Fuel Cap 5. Blade Spacers
3. Pistol Grip Handles
Operation
Note: Determine the left and right sides of the
machine from the normal operating position.
Controls
Operator Presence Control (OPC)
Levers
Located on the upper handle assembly directly above
the handle grips.
When these levers are depressed, the OPC system
senses that the operator is in the normal operator’s
position. When the levers are released, the OPC
system senses that the operator has moved from the
normal operating position and will kill the engine if
either the transmission shift lever is not in the neutral
position or the PTO is engaged (see Figure 4 and
Figure 5).
Figure 4
Pistol Grip Handle
1. Neutral Lock/Park Brake
Latch
4. OPC Lever
2. Rotate latch forward for
park brake position
5. Drive Lever
3. Rotate latch back for
neutral lock position
14
