Carton components
Carton components may vary from one country to another.
Save all packing materials and the printer carton in case for any reason you must ship your printer.
1 Automatic Document Feeder (ADF)
2 Control Panel
3 Front Cover Release Button
4Front Cover
5 Paper Tray
6 Power Switch
7 ADF Document Output Support Flap
8 Document Cover
9 Face-down Output Tray Support
10 Multi-purpose tray (MP tray)
11 USB direct interface
The interface cable is not a standard accessory. Please purchase the appropriate interface cable for the interface
you intend to use (USB or Network). Do NOT connect the interface cable at this time. Connecting the interface
cable is done during the software installation process.
USB interface cable
Please make sure you use a USB 2.0 interface cable that is no longer than 6 feet (2 meters). When you use a
USB cable, make sure you connect it to the USB port of your computer and not to a USB port on a keyboard
or non-powered USB hub.
Network cable
Use a straight-through Category5 (or greater) twisted-pair cable for 10BASE-T or 100BASE-TX Fast Ethernet
Network.
1
2
5
10
4
11
3
9
7
6
8
CD-ROMs
For Windows
®
For Macintosh
®
Quick Setup Guide
User’s Guide
Belt Unit (pre-installed)
AC Power Cord
Insertion Sheet and Plastic
bag for repacking
Waste Toner Box (pre-installed)
Toner cartridges (Black, Cyan, Magenta and Yellow)
Drum Unit (pre-installed)
