WARNING
If you do not understand how a specific control
functions, or have not yet thoroughly read the
FEATURES & CONTROLS section, do so now.
Do NOT attempt to operate the tractor without
first becoming familiar with the location and
function of ALL controls.
Starting the Engine
1. While sitting in the operator’s seat, engage the
parking brake and make sure the PTO switch is
disengaged and the ground speed control levers
are in the NEUTRAL position.
2. NOTE: A warm engine may not require
choking.
Set the engine throttle control to FAST throttle
position. Then fully close the choke by pulling the
knob OUT fully.
3. Insert the key into the ignition switch and turn it to
START.
4. After the engine starts, gradually open the choke
(push knob down fully). Reduce to half throttle
speed and allow the engine to warm up.
Warm up the engine by running it for at least a minute
before engaging the PTO switch or driving the rider.
5. After warming the engine, ALWAYS operate
the unit at FULL THROTTLE when mowing.
In the event of an emergency the engine can be
stopped by simply turning the ignition switch
to STOP. Use this method only in emergency
situations. For normal engine shut down follow the
procedure given in STOPPING THE RIDER.
Stopping the Rider
1. Releasing the ground speed control levers so they
can return to the NEUTRAL position will stop rider
movement.
2. Disengage the PTO by pushing down on the PTO
switch.
3. Engage the parking brake by pulling the handle
back until it locks into position.
4. Move the throttle control to mid-throttle position
and turn the ignition key to OFF. Remove the
key.
Pushing the Rider by Hand
1. Disengage the PTO, engage the parking brake,
turn the ignition OFF, and remove the key.
2. To disengage the pumps (free-wheel position),
turn the hydraulic release valves (A, Figure 2)
located on the pumps COUNTER-CLOCKWISE a
maximum of 2 full turns.
4. Disengage the parking brake.
The unit can now be pushed by hand.
5. After moving the unit, re-engage the pumps
(drive position) by turning the release valves
CLOCKWISE and tighten to 80-120 in. lbs. of
torque.
DO NOT TOW RIDER
Towing the unit will cause hydraulic pump
and wheel motor damage. Do not use
another vehicle to push or pull this unit.
Operation
Figure 2. Hydraulic System By-Pass
A. Hydraulic Release Valve
(left-hand pump shown)
A
