11
To increase the level of discrimination, press the DISCRIMINATION ▲
touch pad. Each time the ▲ pad is depressed, an additional "R" will
appear, thus eliminating from detection the objects which fall into the
corresponding categories.
To decrease the level of discrimination, press the DISCRIMINATION
▼
touch pad. Each time the ▼ pad is depressed, an illuminated "R" will
disappear, thus returning to detection the objects which fall into the
corresponding categories.
Discrimination Mode is a fixed-start-point elimination system. Objects
are cumulatively eliminated as the level of discrimination increases.
NOTCH MODE
To selectively eliminate a category from detection within the metallic
spectrum, use the NOTCH Mode.
Technical Note:
The NOTCH touch pad causes the status of an "R" segment to
toggle between ON and OFF.
To use the NOTCH Mode:
The NOTCH touch pad can be depressed at any time. But for
first-time use, place the detector in ALL-METAL mode.
A first demonstration is best accomplished as follows:
1) Turn the power OFF.
2) Turn the power ON.
3) Press NOTCH.
A flashing "R" will appear under the IRON segment.
4) Press the DISCRIMINATION
▲ touch pad several times
Notice that the "R" moves upon each press of the
DISCRIMINATION
▲ touch pad.
5) Press NOTCH again.
The flashing "R" will become permanently illuminated.
If an object has been “notched-out”, you can return it to detection
status. To “un-notch” a category:
1) Press NOTCH.
2) Move the flashing “R” over the permanently illuminated “R”.
3) Press NOTCH again.
BASIC OPERATION
