24 Chapter 3
Operation Verification
Checking the Maximum Leveled Power
NOTE For Option 1EH and Option UNW, use the data sheet to determine low band power level
limits.
E8257D
Option 520
With Option 1E1
11 dBm 15 dBm 250 kHz 3.2 GHz 50
11 dBm 18 dBm 3.21 kHz 20 GHz 200
E8257D
Option 540
With Option 1E1
7 dBm 14 dBm 250 kHz 3.2 GHz 50
7 dBm 16 dBm 3.21 kHz 20 GHz 200
7 dBm 12 dBm 20.1 GHz 40 GHz 200
E8257D
Option 550 and
Option 567
With Option 1E1
3 dBm 13 dBm 250 kHz 3.2 GHz 50
3 dBm 14dBm 3.21 kHz 20 GHz 200
3 dBm 10 dBm 20.1 GHz 60 GHz 200
3 dBm 8 dBm 60.1 GHz 67 GHz 100
Table 3-1 Frequency and Power Level Limits
Instrument Option Amplitude
Standard Option 1EA
Start
Frequency
Stop
Frequency
# Points
