Connection
If the RS-232C cable is not correctly connected between this product and the PC, no
acknowledgement is transmitted. Connect the RS-232C cable correctly, and fix it firmly with
the connector set screws before the operation.
Function
Command
Parameter Data
Image rotation RO
0 (0°)
1 (90°)
2 (180°)
3 (270°)
■ ■
Aperture
selection
White balance
selection
AP
AW
■ ■
■ ■
0 (OFF)
1 (ON)
0 (OFF)
1 (AUTO)
2 (
ONE-PUSH
)
F.A.M.
selection
CL
■ ■
0 (OFF)
1 (ON)
Comments
Image Store IS
■ ■
1
2
3
4
5
6
7
8
Image Read IC
■ ■
1
2
3
4
5
6
7
8
Contrast CT
■ ■
0 (OFF)
1 (ON)
Local Lockout LL
■ ■
0 (OFF)
1 (ON)
Default DF
■ ■
0
Status request QS
■ ■
0
2
7
8
Rom version QR
■ ■
0
ACK check SA
■ ■
0 (OFF)
1 (ON)
CR addition SC
■ ■
0 (OFF)
1 (ON)
"■ ■" in the data column means that the SPACE [20H] should be transmitted twice.
