Iris
To adjust the brightness of image by adjusting the lens opening.
Auto iris ........... Adjusts brightness automatically.
Manual iris ....... Adjusts brightness manually.
Auto iris adjustment
To adjust the level of brightness automatically
according to the object.
Press the iris button [OPEN] on the front panel or the
[IRIS
.
OPEN] button on the wireless remote control to
open the iris.
Press the iris button
[CLOSE] on the front panel or the
[IRIS
.
CLOSE] button on the wireless remote control to
close the iris.
Press the [IRIS
.
NORMAL] button on the wireless
remote control,to change setting back to the defaults.
Press and hold the auto/manual selection button
[AUTO
.
MANUAL] on the front operation panel for
more than 4 seconds or press the [IRIS
.
NORMAL]
button on the wireless remote control to return to the
initial setting.
PAU S E
2x
SET
PRESET
LIVE
MEMORY
CALL
SET
CALL
LAMP
POSI/NEGA COLOR/B&W
UPPER BASE
IRIS
AF
NORMAL OPEN CLOSE
TELE
ZOOM
WIDE
NEAR
FOCUS
FAR
RGB1 RGB2MAIN
MONITOR
OUTPUT
MONITOR OUTPUT
PAUSE
F.A.M.
MAIN
RGB1
RGB2
IRIS
OPEN CLOSE
ZOOM
TELE
WIDE
POSI / NEGA
IMAGE ROTATION
AUTO/MANUAL
CONTRAST
WHITE
BALANCE
LAMP
UPPER / BASE / OFF
AF
IRIS
OPEN CLOSE
POSI / NEGA
A
GE ROTATION
AUTO/MANUAL
CON
T
WH
BA
L
LAMP
UPPER / BASE / OFF
IRIS
AF
NORMAL OPEN CLOSE
NEAR FAR
1
2
3
4
5
6
7
8
9
10
11
29
Front operation panel
Wireless remote control
Front operation panel
Wireless remote control
