ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
Use only genuine Walker
®
replacement parts. Effective Date 03-31-08
72
60 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 2911)
Spring and Pivot Mount Components
1 2744-1 Spring Clip Bracket 1
2 5975-3 Cable Tie (50# x 7") 2
3 5743-1 Spring Cover 2
4 5743-6 Extension Spring (1-1/2 x 7-3/4) 2
(Includes Items # 2, F117 & F166)
5 5743-4 Eye Bolt (3/8-16 x 2-3/4) 2
6 2723 Counter Weight Spring Mount 2
7 2723-5 Locking Arm, LH (Includes Item # F432) 1
8 5830 Grease Fitting 10
9 2667-1 Pivot Mount, LH (Includes Item # 8) 1
10 2723-4 Pivot Shaft 2
11 2667-2 Pivot Mount, RH (Includes Item # 8) 1
12 2723-6 Locking Arm, RH (Includes Item # F432) 1
Carrier Frame Components
13 2215-2 Gas Spring Cover, RH 1
14 2723-2 Outer Height Adjustment Plate 1
15 7775-5 Lock Pin (5/16) 2
16 2720-3 Height Adjustment Spacer 4
17 2723-1 Inner Height Adjustment Plate 1
18 2215-3 Gas Spring Cover, LH 1
19 8740 Deck Pin Bushing (3/4 ID) 4
20 2911-2 60SD Carrier Frame 1
21 8811-25 Tilt Bar W/Grip (35") 1
(Includes Item # 22)
22 5850-5 Handle Grip (1 x 1 x 3-3/4) 1
Caster Wheel Components
23 8769-8 Dust Cap, Deck Caster 2
24 8769-6 Bearing Cone (1" ID) 4
25 8769-5 Bearing Cup (2 x 1-5/8) 4
26 8769-7 Seal 2
27 2770 Caster Wheel Fork 2
28 7038 Tail Wheel Axle (3/4 x 5-9/16) 2
29 8037-1 Seal, Outer (1-3/4 x 1-1/8) 2
30 8037 Bearing Cone (3/4 ID) 4
31 8035 Tail Wheel & Tire (13 x 5.00-6) 2
(W/Bearing Race)
32 8768-2 Seal, Reverse Lip 2
33 8038-1 Spacer, Tail Wheel Axle 2
(.750 x ID x 1.125 OD)
34 8039 Nut, Tail Wheel Axle 2
Deck Lift Components
35 2722-1 Deck Height Adjustment, LH 1
(Includes Item # 8)
36 2214-10 Rod End, Female (3/8-24) 4
37 2722-3 Pivot Shaft 2
38 2655 Lift Chain 4
39 4407-4 Bow Tie Cotter Pin 2
40 2215-4 Height Adjustment Rod 2
41 5146 10mm Ball Stud 4
42 2215 Gas Spring Assembly 2
43 2721 Lifting Arm (Includes Item # 8) 1
44 2721-2 Lifting Cross Tube 1
45 2723-3 Height Adjustment Arm 1
(Includes Item # 46)
46 5850-3 Handle Grip, Foam (3-1/4) 1
47 2722-2 Deck Height Adjustment Trigger 1
(Includes Item # 8)
Fasteners
F004 1/4-20 Keps Nut 6
F009 5/16-18 Whiz Locknut 12
F013 3/8-16 Whiz Locknut 14
F014 3/8-16 ESNA Nut 2
F035 5/16-18 x 1-1/4 Hex Bolt 2
F038 3/8-16 x 1 Hex Bolt 2
F039 3/8-16 x 1-1/4 Hex Bolt 2
F040 3/8-16 x 1-1/2 Hex Bolt 5
F048 1/2 SAE Washer 2
F050 1/4 SAE Washer 6
F071 3/4 External Snap Ring 2
F090 1/4-20 x 2-1/2 Hex Bolt 4
F117 Retainer Ring 2
F132 1/4-20 x 2-3/4 Hex Bolt 2
F166 Retainer Ring 2
F205 5/16-18 x 1/4 Set Screw (Knurl Point) 2
F215 3/8-16 x 1/2 x 1/2 S Bolt 2
F218 7/16 Split Lock Washer 4
F219 7/16-14 x 1-1/4 Hex Bolt 4
F226 5/16-18 x 7/8 Hex Bolt 4
F241 .375 x .875 x .10 Washer 18
F263 1-1/4 External Snap Ring 6
F268 5/16-18 x 3 Hex Bolt 1
F298 3/8-24 Jam Nut 4
F344 3/4-16 Slotted Hex Nut 2
F347 3/4 SAE Washer 2
F348 1/8 x 1-1/2 Cotter Pin 2
F378 3/8-16 x 6 Hex Bolt 1
F432 3/16 x 1/2 Split Spring Pin 2
F436 3/16 x 1-1/8 Spring Pin 4
F437 Clevis Pin (1/4 x 1) 2
F438 5/16-18 x 2-3/4 Hex Bolt 1
