ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
Use only genuine Walker
®
replacement parts. Effective Date 03-31-08
60
BODY / CHASSIS ASSEMBLY
Body & Seat Assembly
1 2103-1 Seat 1
2 2105-1 Rear Body (Includes Item # 3) 1
3 2190-1 Insulation Foam Pad 1
4 5845 Rubber Bumper (1.50 x 1.25) 2
5 5146 10mm Ball Stud 2
6 2145 Gas Spring 1
7 5180 Edge Molding, Lever Opening 2
8 2100-3 Front Body Doubler 1
9 2504-4 Hinge (22.5) 1
10 2100-1 Front Body 1
11 5989-5 Dome Plug (7/16) 1
12 2383 Body Latch Hook 1
13 7854 Plastic Tip, Red 1
14 7222 Extension Spring (1/4 x 3) 1
15 5989-4 Dome Plug (3/8) 2
16 5989-3 Dome Plug (5/16) 2
Chassis Assembly
17 2390-1 Battery Pan 1
18 2046-1 Gas Tank Mount, LH 1
19 2300-3 Chassis Frame 1
20 2046 Gas Tank Mount 1
Tail Wheel Assembly
21 5830 Grease Fitting 4
22 2201-2 Fiberglide Thrust Washer 2
23 2201-3 Fiberglide Bearing (1-5/8) 2
24 2300-6 Tail Wheel Pivot (Includes Items # 21 & 25)1
25 5830-3 Grease Fitting (45 Deg.) 1
26 2201-4 Washer (2-1/4 x 7/16 x 1/4 Thk) 1
27 8769-8 Dust Cap, Deck Caster 2
28 8769-6 Bearing Cone (1" ID) 4
29 8769-5 Bearing Cup (2 x 1-5/8) 4
30 8769-7 Seal 2
31 2770 Caster Wheel Fork 2
32 8039 Nut, Tail Wheel Axle 2
33 8038-1 Spacer, Tail Wheel Axle 2
(.750 x ID x 1.125 OD)
34 8768-2 Seal, Reverse Lip 2
35 8037 Bearing Cone (3/4 ID) 4
36 8035 Tail Wheel & Tire (13 x 5.00-6) 2
(W/Bearing Race)
37 8037-1 Seal, Outer (1-3/4 x 1-1/8) 2
38 7038 Tail Wheel Axle (3/4 x 5-9/16) 2
Deck Support Arm & Hitch Assemblies
39 2300-9 Deck Arm Support Mount 1
40 6840-1 Support Arm Bushing (2-1/16) 2
41 2775 Lynch Pin (5/16 x 1-1/4) 2
42 2431 Deck Support Arm, LH 1
(Includes Item # 21)
43 2430 Deck Support Arm, RH 1
(Includes Item # 21)
Deck Arm Adapter Kit
*
44 2431-1 Deck Arm Adapter, LH 1
45 5775-2 Hitch Pin (#6) 2
46 2430-1 Deck Arm Adapter, RH 1
47 2744-2 Counter Weight Spring Extension 1
48 2744-4 1/4" Quick Link 1
49 2744-5 Chain 1
Tilt-Up Latch Assembly
**
50 5847 Plastic Tip 1
51 5744-20 Spring Arm, Tilt-Up Latch 1
52 5744-10 Spring Pivot Bushing 1
53 5744-15 Compression Spring (3/8 x 5/8) 1
54 5744-13 Mount Angle, LH 1
55 5744-12 Hook, Tilt-Up Latch 1
56 5744-14 Mount Angle, RH 1
Fasteners
F002 10-24 Keps Nut 5
F004 1/4-20 Keps Nut 11
F005 1/4-20 ESNA Nut 2
F009 5/16-18 Whiz Locknut 16
F013 3/8-16 Whiz Locknut 2
F020 5/16-18 ESNA Nut 1
F025 10-24 x 3/8 PPHMS 5
F029 1/4-20 x 1/2 Hex Bolt 2
F034 5/16-18 x 3/4 Hex Bolt 8
F093 5/16-18 x 1 Hex Bolt 1
F151 3/8-16 x 7/8 Hex Bolt 2
F183 .312 x .700 x .074 Washer 4
F205 5/16-18 x 1/4 Set Screw (Knurl Point) 2
F218 7/16 Split Lock Washer 5
F219 7/16-14 x 1-1/4 Hex Bolt 5
F236 1/4-20 x 1-3/4 Hex Bolt 2
F246 1/4-20 x 1/2 PTHMS 4
F256 7/16 SAE Washer 1
F341 Coil Roll Pin (7/64 x 9/16) 1
F342 5/16 Conical Washer 2
F344 3/4-16 Slotted Hex Nut 2
F347 3/4 SAE Washer 2
F348 1/8 x 1-1/2 Cotter Pin 2
F430 7/16-20 ESNA Nut 2
F442 1/4-20 x 5/8 PTHMS 5
F446 7/16-20 x 3-1/2 Grd 8 Bolt 2
* Complete Deck Arm Adapter Kit available by ordering
kit 2430-10. This kit allows the use of all Side Discharge
Decks with the MBSSD Tractor.
** Complete Tilt-Up Latch Assembly Kit available by ordering
kit # 5747.
