Swim'n Play side deck Swimming Pool User Manual



15
Using the illustration for your size deck on the previous page, assemble
the Fence Postions. Note carefully the location for the different sizes.
Attach the Fence portions to the Fence Brackets using the ½” Sheet
Metal Screws as illustrated below. Slip a protective Rubber Screw
Cap on the exposed end of each screw.
Attach the Universal Fence Brackets to the top of
the End or Corner Posts simply by inserting the
oval end into the slot in the Post and pressing
down as shown.
Next, press one Post Cap to the top of each Post.
END POST
OR
CORNER POST
STANDARD POST
FENCE BRAKET
INSERTED
THROUGH POST
Attach the Straight Fence Brackets to the top of the Standard
Posts simply by inserting the shorter end through the slots in
the Post until it stops.
Next, press one Post Cap to the top of each Post.
VIEWED FROM OUTSIDE OF POOL
1/2" Sheet
Metal Screw
Ruber Cap
16
15
1/2” SHEET
METAL
SCREW
