English – 5
ASSEMBLY
PLACING THE GRASS COLLECTOR ON
THE TRACTOR (FIG. 6)
Fig. 6
Proceed to the following steps:
1. Lift the grass collector assembly with both
hands. Slant it to an angle of approximately 40°
(fig. 6).
2. Slide the grass collector on the two support
brackets located on the rear of the tractor.
3. When the grass collector is properly positioned,
place the decal with the triangle symbol directly
opposite to the symbol on the rear of the tractor.
This will assist alignment in the future (Fig. 7).
PREPARATION BEFORE THE FIRST
OPERATION
The tractor is shipped without gas, oil and electrolyte in
the battery, for safety reasons.
!!
DANGER
Lead acid batteries generate explosive gases. Keep
sparks, flame, and smoking materials away from
batteries. Always wear eye protection when around
batteries.
BATTERY PREPARATION
Battery provides maintenance free performance. Flush
cover battery is completely leakproof and spillproof
when tipped to a 45 degree angle, so you do not have to
worry about electrolyte leakage when performing routine
maintenance.
The battery is placed under the seat, and can be accessed
by tilting the seat in the upright position (Fig. 8).
NOTE: The battery is shipped with electrolyte!
Fig. 8
DISTILLED
WATER
!
!
WARNING
This tractor is equipped with a safety micro-switch
and the cutting system will not function when the
grass collector assembly is not in place. Do not tamper
with this micro-switch.
Fig. 7
