English – 9
OPERATION
Move the throttle to slow position before turning
ignition off, in order to reduce muffler pop. Failure
to do so will result in engine and exhaust damages.
!!
WARNING
The mower deck must be in the highest position, when
you drive the tractor in transport mode off the lawn. If
not, damages will be caused to the blades.
IMPORTANT
!
!
WARNING
In case the tractor must be pushed, the transmission
disengagement bypass lever must be put in the
forward position.
RIDING THE TRACTOR
The tractor is equipped with a hydrostatic transmission.
It means that the forward and reverse speed can be
achieved with the use of the pedals (Fig. 15).
The more depressed the pedals are, the faster the tractor
moves. The tractor moves forward and reverse at the
same speed.
BRAKE (FIG. 14)
When the pedal is fully depressed, the brake is applied.
Then, place the throttle lever at the "turtle" idle position
(fig. 17).
The parking brake lever is used to lock the brake pedal
in brake position (fig. 14; pos. 2).
REVERSE GEAR (FIG. 15)
!!
CAUTION
Come to a full stop before changing direction of
motion.
Depress slowly the reverse movement pedal
(Fig. 15, pos. 2).
!
!
WARNING
While riding backwards, watch out behind.
Do not have your mower engaged!
LAWN CUTTING
• Clear the area of any objects, such as toys,
wires, branches, etc.
• Do not wear loose clothes, which could be
caught in moving parts.
• Always wear substantial footwear.
• Keep out children and animals, while riding.
• Keep hands and feet away from the mower
deck.
• Never carry passengers.
IMPORTANT
Be sure the cutting system clutch is disengaged and is in
the OFF position before starting engine (fig. 16).
Fig. 16
BLADES CHECK
Check the cutting blades periodically.
If dull, you will not get a nice event cut.
You must replace or sharpen the blades.
After sharpening, you must balance the blades before re-
installation.
CUTTING HEIGHT ADJUSTMENT
(FIG.19)
The cutting height lever is located on the right side of
fender.
The bottom position of the lever is the lowest cutting
height, and vice versa.
