15
Item Part# Description Qty Item Part# Description Qty
1 39275 Housing 1 14 39288 Pin, 8x20mm 2
2 39276 Shaft 1 15 39289 Cap 3
3 39277 Gear 1 16 39290 Breather plug, 3/8” 1
4 39278 Flange 1 17 31762 Oil plug, 3/8” 1
5 39279 Shaft 1 18 39292 Drain plug, 3/8” 1
6 39280 Housing 1 19 39293 Cap 1
7 31766 Circlip 1 20 39294 Cap 2
8 39282 Oil seal, 25x52x10mm 1 21 39295 Sight glass 1
9 39283 Oil seal, 35x52x10mm 1 22 39296 Screw, M8 x 20mm 2
10 39284 Key, 10x8x25mm 1 23 39297 Screw, M8 x 40mm 6
11 39285 Bearing 3 24 39298 Screw, M8 x 110mm 2
12 31760 Bearing 1 25 39299 Sleeve 2
13 39287 Nut, M8 8
Any Questions, Comments, Problems or Parts Orders
Call NorthStar Product Support 1-800-270-0810
Item# 38890
Gearbox
Parts Explosion
Revision C
Note: Gearbox exploded view
is shown upside-down when
compared to its orientation on
the generator.
